Single door, 3x GbE RJ45, PoE++, polycarbonate, metal, 113 x 66 x 27.6 mm
Key Features
- (1) Lock terminal (12V and Dry switchable)
- (2) Additional inputs (sensor and button)
- Connect and power via PoE++
- Connect up to two UniFi Access Readers or Protect Cameras
Description
Compact Access Control Hub for a single door.
Specifications
| Technical details |
|---|
| Maximum number of doors |
1 door(s) |
| Interface |
Ethernet |
| Exit request |
Yes |
| LED indicators |
Yes |
| Compliance certificates |
CE, Federal Communications Commission (FCC), Industry Canada (IC) |
| Performance |
|---|
| Ethernet LAN |
Yes |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Power |
|---|
| DC voltage range |
50 V |
| Ports & interfaces |
|---|
| Ethernet LAN (RJ-45) ports |
3 |
| Operational conditions |
|---|
| Operating temperature (T-T) |
-10 - 40 °C |
| Operating relative humidity (H-H) |
5 - 90% |
| Weight & dimensions |
|---|
| Width |
66 mm |
| Weight |
190 g |
| Height |
113 mm |
| Depth |
27.6 mm |
