96 Superlik clients, up to 2 km, 7 UP Sense (BLE) devices, status LED, 10/100 MbE RJ45 port, Bluetooth 5.2, USB Type-C (5V, 1A), PoE, Wall, DIN rail, 179 g
Description
Specifications
| Design | |
|---|---|
| LED indicators | Status |
| Mounting type | DIN-rail/Wall mounting |
| Product colour | White |
| Features | |
| Antenna type | External |
| Antenna gain level (max) | 3 dBi |
| Antennas quantity | 1 |
| Performance | |
| Control display unit | No |
| Mounting type | DIN-rail/Wall mounting |
| Product colour | White |
| Network | |
| Ethernet LAN data rates | 10,100 Mbit/s |
| Bluetooth version | 5.2 |
| Bluetooth Low Energy (BLE) | Yes |
| Bluetooth | Yes |
| Ports & interfaces | |
| Ethernet LAN (RJ-45) ports | 1 |
| Management features | |
| Reset button | Yes |
| Power | |
| Power over Ethernet (PoE) | Yes |
| Power consumption (max) | 3.4 W |
| Weight & dimensions | |
| Weight | 179 g |
| Width | 81.9 mm |
| Height | 159.3 mm |
| Depth | 26 mm |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Technical details | |
| Antenna type | External |
| Antenna gain level (max) | 3 dBi |
| Compliance certificates | CE, Federal Communications Commission (FCC), Industry Canada (IC) |
| Indication | |
| LED indicators | Status |
| Display | |
| Control display unit | No |
| Certificates | |
| Compliance certificates | CE, Federal Communications Commission (FCC), Industry Canada (IC) |
| Antenna | |
| Antenna type | External |
| Antenna gain level (max) | 3 dBi |
| Antennas quantity | 1 |
