75", 3840 x 2160, 400 cd/m2, 4C 2.2Ghz + 4C 2Ghz, 8GB RAM, 3x 50MP Sony Sensor X3, 16 MEMS, Wi-Fi 6, Bluetooth 5.1, Android 13.0
Description
The MeetingBoard Pro combines video conferencing, display, and smart whiteboarding into a sleek, all-in-one solution with plug-and-play convenience and a clutter-free design. Delivering Pro View, Pro Sound, and powered by Pro Core, it features a triple 50MP camera system with advanced AI for precise tracking and a 16 MEMS mic array with AI-enhanced audio for crystal-clear conversations up to 12m. MeetingBoard Pro supports Android solution or Windows solution. Built on Android 13 with MDEP security and compatible with Teams, Zoom, and BYOD, it’s the ultimate meeting solution, expandable with plug-and-play add-ons like 12x Pro PTZ cameras and extension mics.
Specifications
| Display |
|---|
| Display diagonal |
190.5 cm (75") |
| Display technology |
LCD |
| Display resolution |
3840 x 2160 pixels |
| Viewing angle |
178° |
| Touchscreen |
Yes |
| Touchscreen technology |
Infrared |
| Display brightness |
400 cd/m² |
| Contrast ratio (typical) |
1200:1 |
| Number of simultaneous touchpoints |
20 |
| Maximum refresh rate |
60 Hz |
| Anti-glare surface |
Yes |
| Design |
|---|
| VESA mounting |
Yes |
| Panel mounting interface |
800 x 600 mm |
| LED indicators |
Yes |
| Operating temperature (T-T) |
0 - 40 °C |
| Storage temperature (T-T) |
-20 - 60 °C |
| USB port |
Yes |
| Performance |
|---|
| Built-in processor |
Yes |
| Processor cores |
8 |
| RAM capacity |
8 GB |
| Storage capacity |
64000 MB |
| Operating system installed |
Android |
| Video formats supported |
H.264 |
| Audio |
|---|
| Built-in speaker(s) |
Yes |
| Built-in microphone |
Yes |
| Number of microphones |
16 |
| Camera |
|---|
| Built-in camera |
Yes |
| Total megapixels |
50 MP |
| Maximum resolution |
3840 x 2160 pixels |
| Field of view (FOV) angle |
98.2° |
| Network |
|---|
| Wi-Fi standards |
802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax) |
| Bluetooth |
Yes |
| Bluetooth version |
5.1 |
| Wi-Fi |
Yes |
| Ethernet LAN |
Yes |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Ports & interfaces |
|---|
| USB port |
Yes |
| HDMI input ports quantity |
1 |
| HDMI output ports quantity |
1 |
| RJ-45 ports quantity |
4 |
| USB 2.0 Type-A ports quantity |
3 |
| HDMI ports quantity |
2 |
| Power |
|---|
| Power source type |
AC |
| Input voltage |
100 - 240 V |
| Power consumption (max) |
277 W |
| Power consumption (average) |
164 W |
| Weight & dimensions |
|---|
| Width |
1705 mm |
| Depth |
105 mm |
| Height |
1081 mm |
| Weight |
52.2 kg |
| Packaging data |
|---|
| Package width |
1900 mm |
| Package depth |
225 mm |
| Package height |
1160 mm |
| Package weight |
65 kg |
| Packaging content |
|---|
| Cables included |
AC, LAN (RJ-45) |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 40 °C |
| Storage temperature (T-T) |
-20 - 60 °C |
| Operating relative humidity (H-H) |
5 - 95% |
| Features |
|---|
| Built-in speaker(s) |
Yes |
