Description
Infosec E3 Performance 800 RT, Double-conversion (Online), 0.8 kVA, 720 W, Sine, 81 V, 290 V
Description
Infosec E3 Performance 800 RT. UPS topology: Double-conversion (Online), Output power capacity: 0.8 kVA, Output power: 720 W. AC outlets quantity: 8 AC outlet(s). Battery recharge time: 4 h. Form factor: Rackmount/Tower, Product colour: Black, Rack capacity: 2U. Compliance certificates: RoHS, Certification: EN62040-2: 2006+AC: 2006 (EN 61000-3-2: 2014, EN61000-4-2:2009, EN61000-4-3:2006+A2: 2010,...Specifications
| Power | |
|---|---|
| Output power | 720 W |
| Input operation voltage (min) | 81 V |
| Input operation voltage (max) | 290 V |
| Output operation voltage (min) | 110 V |
| Output operation voltage (max) | 240 V |
| Efficiency | 97% |
| Emergency Power Off (EPO) | Yes |
| Power factor | 0.9 |
| Output voltage Total Harmonic Distortion (THD) | 2% |
| Crest factor | 3:1 |
| Output power capacity | 0.8 kVA |
| Performance | |
| Audible alarm modes | Alarm when on battery, Fault, Low battery alarm, Overload alarm |
| UPS topology | Double-conversion (Online) |
| Waveform | Sine |
| Number of output phases | 1 |
| Number of input phases | 1 |
| LED indicators | Yes |
| Surge protection | Yes |
| Surge protection features | Digital Subscriber Line (DSL), Fax, Modem, Network, Telephone |
| Power protection features | Over voltage, Overdischarge, Overload |
| Noise level | 45 dB |
| Audible alarm(s) | Yes |
| Features | |
| Output frequency | 50/60 Hz |
| Audible alarm modes | Alarm when on battery, Fault, Low battery alarm, Overload alarm |
| UPS topology | Double-conversion (Online) |
| Waveform | Sine |
| Number of output phases | 1 |
| Number of input phases | 1 |
| Output power | 720 W |
| Input operation voltage (min) | 81 V |
| Input operation voltage (max) | 290 V |
| Output operation voltage (min) | 110 V |
| Output operation voltage (max) | 240 V |
| Efficiency | 97% |
| Surge protection | Yes |
| Surge protection features | Digital Subscriber Line (DSL), Fax, Modem, Network, Telephone |
| Emergency Power Off (EPO) | Yes |
| Power protection features | Over voltage, Overdischarge, Overload |
| Power factor | 0.9 |
| Output voltage Total Harmonic Distortion (THD) | 2% |
| Noise level | 45 dB |
| Crest factor | 3:1 |
| Audible alarm(s) | Yes |
| Output power capacity | 0.8 kVA |
| Input frequency | 50/60 Hz |
| Ports & interfaces | |
| Emergency Power Off (EPO) connector | Yes |
| USB port | Yes |
| Serial interface | Yes |
| AC outlets quantity | 8 AC outlet(s) |
| USB 2.0 ports quantity | 1 |
| RS-232 ports | 1 |
| Modem (RJ-11) ports | 2 |
| Ethernet LAN (RJ-45) ports | 2 |
| Battery | |
| Battery recharge time | 4 h |
| Design | |
| Rack capacity | 2U |
| Form factor | Rackmount/Tower |
| LED indicators | Yes |
| Product colour | Black |
| Certification | EN62040-2: 2006+AC: 2006 (EN 61000-3-2: 2014, EN61000-4-2:2009, EN61000-4-3:2006+A2: 2010, EN61000-4-4: 2012, EN61000-4-5: 2006, EN61000-4-6: 2014, EN61000-4-8: 2010, EN61000 -2-2: 2002) EN62040-1:2008+A1:2013 |
| Display type | LCD |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 0 - 90% |
| Technical details | |
| Output frequency | 50/60 Hz |
| Compliance certificates | RoHS |
| Certificates | |
| Certification | EN62040-2: 2006+AC: 2006 (EN 61000-3-2: 2014, EN61000-4-2:2009, EN61000-4-3:2006+A2: 2010, EN61000-4-4: 2012, EN61000-4-5: 2006, EN61000-4-6: 2014, EN61000-4-8: 2010, EN61000 -2-2: 2002) EN62040-1:2008+A1:2013 |
| Compliance certificates | RoHS |
| Weight & dimensions | |
| Weight | 12.9 kg |
| Width | 438 mm |
| Height | 88 mm |
| Depth | 425 mm |
| Packaging data | |
| Bundled software | InfoPower |
| Packaging content | |
| Bundled software | InfoPower |
