65" All-in-One PCAP Interactive Display for Smart Collaboration Spaces
Reasons To Buy
Android OS
Thanks to Android OS, you can easily customize the display to your needs by installing applications directly to it.
iiSignage²
iiSignage² is our digital signage content management platform to easily show and control your content and to manage your displays in a secure way. The Content Management System (CMS) gives you total control of your messaging and advertising remotely and safely.
Huddle Spaces
Turn these small meeting rooms into neat Collaboration spaces by employing the embedded applications like Android OS, EShare and Whiteboard, a selection of intuitive and practical tools installed on our PCAP interactive Touchscreens. With Android OS you can easily customize the display by installing applications directly to it. With the EShare app you can share, stream and edit content from any device directly on screen and transform your team meetings into an easy, fast and seamless interactive session.
USB-C Loop Through
One cable, zero clutter. USB-C Loop Through lets you connect and daisy-chain devices with ease—video, data, and power all in one go. It’s plug, play, and pass it on. Smart connectivity that keeps your setup clean and simple.
Signal FailOver
FailOver is a feature which automatically detects input sources. When there is no signal on the default input it will automatically switch to the next available input. FailOver allows customers to prioritize a number of inputs (incl. Browser, Media Player and Custom) and ensures your content is always actively displayed, assuring active content at all times.
Touch Pens
Two stylish dual tip Touch pens are included and they can be placed at both sides of the display at the magnetic holding spots.
Touch Through-Glass
This through glass touch screen works right through glass and can turn glass surfaces into an interactive touch screen display. Use it on storefront windows, real estate office, in-store for POS or restaurants.
Retail Instalations
The interactive 4K Touchscreens are the key for immersive interactive experiences for spatial retail design. Allow customers to explore your website right there and then or engage with a range of creative or experiential applications you want to host. The flexibility of either landscape or portrait modes with 24/7 Operation, built-in Android and MediaPlayer make this SERIES displays one of the most adaptable Touchscreens solutions around.
Description
The ProLite T6529AS-B1AG is a 65" all-in-one PCAP touchscreen display built for the evolving needs of modern workspaces, especially huddle spaces where creativity, flexibility, and seamless sharing take center stage. Powered by Android OS, this interactive display delivers a user-friendly and highly adaptable experience. You can install your preferred apps directly on the device, enabling customized workflows tailored to your environment — whether in a collaborative meeting area, an enterprise innovation hub, or an educational breakout room. The USB-C loop-through feature simplifies connectivity by allowing multiple displays to be easily daisy-chained while transmitting power, data, and video — all through a single cable. This reduces cable clutter and setup time, making it ideal for dynamic workspaces. The included wall mounting bracket makes installation straightforward and secure. With iiSignage² (CMS), iiControl (DMS), and iiShare (Wireless Presentation) you gain full control over content and messaging, even remotely — perfect for updating shared information or branded visuals on the fly. The integrated EShare app brings wireless screen sharing and collaboration to life, supporting multi-user interaction and real-time ideation. The T6529AS-B1AG isn’t just a display — it’s a collaboration tool designed to empower teams, streamline communication, and make every meeting count.
Specifications
| Display |
|---|
| LED backlight |
Yes |
| Panel type |
VA |
| Display number of colours |
1.07 billion colours |
| Number of simultaneous touchpoints |
20 |
| LED backlighting type |
Direct-LED |
| Touchscreen |
Yes |
| Active display area (W x H) |
1428.5 x 803.5 mm |
| Display technology |
LED |
| Display diagonal |
163.8 cm (64.5") |
| Display resolution |
3840 x 2160 pixels |
| Display brightness |
500 cd/m² |
| HD type |
4K Ultra HD |
| Response time |
6.5 ms |
| Contrast ratio (typical) |
4000:1 |
| Viewing angle, horizontal |
178° |
| Viewing angle, vertical |
178° |
| Pixel pitch |
0.372 x 0.372 mm |
| Display diagonal (metric) |
164 cm |
| Native aspect ratio |
16:9 |
| Horizontal scan range |
28 - 160 kHz |
| Anti-glare screen |
Yes |
| Touchscreen technology |
Projected capacitive system |
| Surface hardness |
8 |
| Multi-touch |
Yes |
| Glass thickness |
3.7 mm |
| Ports & interfaces |
|---|
| Remote (IR) output |
1 |
| Remote (IR) input |
1 |
| USB port |
Yes |
| HDMI version |
1.4/2.0 |
| RS-232C |
Yes |
| Wi-Fi standards |
Wi-Fi 5 (802.11ac) |
| Wi-Fi |
Yes |
| Ethernet LAN |
Yes |
| HDMI ports quantity |
2 |
| DVI port |
No |
| Ethernet LAN (RJ-45) ports |
1 |
| USB version |
2.0 |
| USB ports quantity |
2 |
| USB Type-C DisplayPort Alternate Mode |
Yes |
| Audio |
|---|
| Number of built-in speakers |
2 |
| RMS rated power |
20 W |
| Built-in speaker(s) |
Yes |
| Design |
|---|
| Product design |
Interactive flat panel |
| Placement supported |
Indoor |
| Orientation |
Horizontal/Vertical |
| Product colour |
Black |
| Panel mounting interface |
400 x 400 mm |
| Certification |
CB, CE, TÜV-Bauart, EAC, RoHS support, ErP, WEEE, REACH, UKCA, cTUVus |
| VESA mounting |
Yes |
| Anti-glare screen |
Yes |
| Screen shape |
Flat |
| Performance |
|---|
| Purpose |
Universal |
| Operating hours (hours/days) |
24/7 |
| Mean time between failures (MTBF) |
50000 h |
| On Screen Display (OSD) languages |
Multi |
| On Screen Display (OSD) |
Yes |
| Number of OSD languages |
8 |
| HDCP |
Yes |
| HDCP version |
1.4/2.2 |
| Wi-Fi |
Yes |
| Power |
|---|
| Power consumption (off) |
0.3 W |
| Power consumption (typical) |
118 W |
| Power consumption (standby) |
0.5 W |
| AC input voltage |
100 - 240 V |
| AC input frequency |
50/60 Hz |
| Energy efficiency scale |
A to G |
| Energy efficiency class (SDR) |
G |
| Computer system |
|---|
| Processor cores |
4 |
| Operating system installed |
Android |
| Internal memory |
4 GB |
| Internal storage capacity |
32 GB |
| Processor manufacturer |
ARM |
| Built-in processor |
Yes |
| On-board graphics card model |
ARM Mali-G51 |
| Processor architecture |
ARM Cortex-A73 |
| Operating system version |
14 |
| Weight & dimensions |
|---|
| Width (with stand) |
1447.3 mm |
| Height (with stand) |
852.3 mm |
| Depth (with stand) |
42.8 mm |
| Weight (with stand) |
38.5 kg |
| Display width |
1447.3 mm |
| Display depth |
42.8 mm |
| Display height |
852.3 mm |
| Display weight |
38.5 kg |
| Packaging data |
|---|
| Package width |
1645 mm |
| Package depth |
1645 mm |
| Package height |
1050 mm |
| Package weight |
47.3 kg |
| Quick start guide |
Yes |
| Batteries included |
Yes |
| Remote control included |
Yes |
| Cables included |
AC, HDMI |
| Stylus pen |
Yes |
| Number of stylus pens |
2 |
| Packaging content |
|---|
| Quick start guide |
Yes |
| Batteries included |
Yes |
| Remote control included |
Yes |
| Cables included |
AC, HDMI |
| Stylus pen |
Yes |
| Number of stylus pens |
2 |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 40 °C |
| Operating relative humidity (H-H) |
-20 - 60% |
| Certificates |
|---|
| Certification |
CB, CE, TÜV-Bauart, EAC, RoHS support, ErP, WEEE, REACH, UKCA, cTUVus |
| Technical details |
|---|
| VESA mounting |
Yes |
| Power supply type |
Internal |
| Panel type |
VA |
| Number of simultaneous touchpoints |
20 |
| LED backlighting type |
Direct-LED |
| Weight (with stand) |
38.5 kg |
| Thin Client |
|---|
| Operating system installed |
Android |
| Internal memory |
4 GB |
| Internal storage capacity |
32 GB |
| Other features |
|---|
| Power supply type |
Internal |
| Panel type |
VA |
| Number of simultaneous touchpoints |
20 |
| Wi-Fi standards |
Wi-Fi 5 (802.11ac) |
| Wi-Fi |
Yes |
| Width (with stand) |
1447.3 mm |
| Viewable size, vertical |
80.3 cm |
| Viewable size, horizontal |
142.8 cm |
| Mean time between failures (MTBF) |
50000 h |
| Height (with stand) |
852.3 mm |
| Display technology |
LED |
| Depth (with stand) |
42.8 mm |
| Quick start guide |
Yes |
| Weight (with stand) |
38.5 kg |
| Stylus pen |
Yes |
| Number of stylus pens |
2 |
| Energy efficiency scale |
A to G |
