Description
5-Port, Gigabit, PoE+, 63 W, 128 KB, 2K, 0-40°C, Grey, 158 x 101 x 27 mm, 0.40 kg
4 PoE+ ports delivering up to 30W per port with a 63W total power budget for wireless APs, IP Cameras, IP Phones and much more.
PLUG-AND-PLAY
Simple set up with no software to install or configuration needed
NON-BLOCKING SWITCHING
Non-blocking switching architecture for maximum throughput at wire speed
FANLESS DESIGN
Silent operation makes this switch perfect for noise-sensitive environments
VERSITILE MOUNTING OPTIONS
Install your switch on your desktop or mount it to your wall with the hardware provided in the box
ENERGY EFFICIENT
Energy Efficient Ethernet (IEEE 802.3az) standard, which reduces energy consumption when there is light traffic on an active port or when there is no link or no activity detected Flex PoE
Key Features
- 5 x Gigabit Ethernet ports with PoE
- Plug and play switch, no management required
- Energy Efficient Ethernet for maximum power savings
- Fanless and silent
- Desktop or wall-mount
Description
POWER-OVER-ETHERNET4 PoE+ ports delivering up to 30W per port with a 63W total power budget for wireless APs, IP Cameras, IP Phones and much more.
PLUG-AND-PLAY
Simple set up with no software to install or configuration needed
NON-BLOCKING SWITCHING
Non-blocking switching architecture for maximum throughput at wire speed
FANLESS DESIGN
Silent operation makes this switch perfect for noise-sensitive environments
VERSITILE MOUNTING OPTIONS
Install your switch on your desktop or mount it to your wall with the hardware provided in the box
ENERGY EFFICIENT
Energy Efficient Ethernet (IEEE 802.3az) standard, which reduces energy consumption when there is light traffic on an active port or when there is no link or no activity detected Flex PoE
Specifications
| Management features | |
|---|---|
| Switch type | Unmanaged |
| Quality of Service (QoS) support | Yes |
| Ports & interfaces | |
| Basic switching RJ-45 Ethernet ports quantity | 5 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Copper ethernet cabling technology | 1000BASE-T, 100BASE-T, 10BASE-T |
| Network | |
| Copper ethernet cabling technology | 1000BASE-T, 100BASE-T, 10BASE-T |
| Networking standards | IEEE 802.1p, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az |
| Full duplex | Yes |
| VLAN support | Yes |
| Rate limiting | Yes |
| Port mirroring | Yes |
| Link aggregation | Yes |
| Flow control support | Yes |
| Broadcast storm control | Yes |
| 10G support | No |
| IGMP snooping | Yes |
| Data transmission | |
| Jumbo frames | 9216 |
| Packet buffer memory | 0.128 MB |
| MAC address table | 2000 entries |
| Store-and-forward | Yes |
| Jumbo frames support | Yes |
| Security | |
| IGMP snooping | Yes |
| DHCP features | DHCP client |
| Design | |
| Form factor | Desktop/Wall-Mounting |
| Product colour | Grey |
| Stackable | No |
| LED indicators | Activity, Link, PoE, Power, Speed, Status |
| Housing material | Metal |
| Rack mounting | No |
| Certification | CB, CE LVD, CSA |
| Performance | |
| Mean time between failures (MTBF) | 4113947 h |
| Fanless | Yes |
| Packet buffer memory | 0.128 MB |
| Stackable | No |
| Power | |
| Power consumption (max) | 67.5 W |
| Power supply included | No |
| Input current | 1.66 A |
| DC input voltage | 54 V |
| Power source | AC/DC |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) power per port | 30 W |
| Total Power over Ethernet (PoE) budget | 83 W |
| Power over Ethernet (PoE) ports quantity | 4 |
| Power over Ethernet (PoE) | Yes |
| Other features | |
| Bandwidth | 10 Gbit/s |
| Operational conditions | |
| Storage temperature (T-T) | -20 - 70 °C |
| Storage relative humidity (H-H) | 0 - 95% |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 0 - 90% |
| Operating altitude | 0 - 3000 m |
| Heat dissipation | 3.24 BTU/h |
| Virtual LAN features | |
| VLAN support | Yes |
| Weight & dimensions | |
| Width | 158 mm |
| Depth | 101 mm |
| Height | 27 mm |
| Weight | 400 g |
| Packaging content | |
| Quick start guide | Yes |
| Technical details | |
| Form factor | Desktop/Wall-Mounting |
| Product colour | Grey |
| Stackable | No |
| Mean time between failures (MTBF) | 4113947 h |
| Housing material | Metal |
| Rack mounting | No |
| Compliance certificates | CB, CE, Federal Communications Commission (FCC) |
| Memory | |
| Packet buffer memory | 0.128 MB |
| Certificates | |
| Certification | CB, CE LVD, CSA |
| Compliance certificates | CB, CE, Federal Communications Commission (FCC) |
| Indication | |
| LED indicators | Activity, Link, PoE, Power, Speed, Status |
| Packaging data | |
| Quick start guide | Yes |
