Ethernet Surge Protection, 2x RJ45 female, 90V @ 100V/s, 600V @ 1kV/µs, 89 x 25.5 x 37.4 mm
Key Features
- Wall/DIN rail mount
- Multiple grounding points
Description
Bidirectional protection for up to 10 GbE, PoE++, and 20kA surge discharge for indoor installation.
Specifications
| Power |
|---|
| Maximum voltage (Data side) |
600 V |
| Ports & interfaces |
|---|
| Ethernet LAN (RJ-45) ports |
2 |
| Data transfer rate |
10 Gbit/s |
| Features |
|---|
| Material |
Polycarbonate (PC), SGCC |
| Product colour |
Grey |
| Wall mountable |
Yes |
| Weight & dimensions |
|---|
| Weight |
74 g |
| Width |
25.5 mm |
| Depth |
89 mm |
| Height |
37.4 mm |
| Operational conditions |
|---|
| Operating temperature (T-T) |
-40 - 80 °C |
| Operating relative humidity (H-H) |
10 - 90% |
