ThinkPad USB 3.0 Ultra Dock
Description
The ThinkPad USB 3.0 Ultra Dock is an universal USB docking solution that not only delivers a premium display experience (up to 4k2k resolution via DP port), but also provides quick and easy connection to all the workspace peripherals you use every day. Simply plug in a single USB 3.0 cable into your Lenovo PC for instant access to up to two external monitors, USB ports, Gigabit Ethernet, headphones/speakers, USB printers, scanners, keyboard, mouse and so on for daily use. The Dock can also charge your mobile devices via two USB always power on ports.
Specifications
| Ports & interfaces |
|---|
| Combo headphone/mic port |
Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
5 |
| Headphone connectivity |
3.5 mm |
| Host interface |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A |
| USB 2.0 ports quantity |
2 |
| Ethernet LAN (RJ-45) ports |
1 |
| HDMI ports quantity |
1 |
| DisplayPorts quantity |
1 |
| Microphone in |
Yes |
| Headphone outputs |
1 |
| DC-in jack |
Yes |
| Connectivity technology |
Wired |
| Network |
|---|
| Ethernet LAN |
Yes |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Ethernet LAN (RJ-45) ports |
1 |
| Performance |
|---|
| Product colour |
Black |
| Card reader integrated |
No |
| Brand compatibility |
Lenovo |
| Certification |
FCC/ICES
CE
KCC
RCM
BSMI
VCCI
CB
UL+cUL
EAC
TUV
Mark
Serbia Kvalitet
South Africa SABS&LoA
Israel SII
Ukraine DoC |
| Technical details |
|---|
| Product colour |
Black |
| Brand compatibility |
Lenovo |
| Harmonized System (HS) code |
84733020 |
| Storage |
|---|
| Card reader integrated |
No |
| Power |
|---|
| Power source type |
DC |
| Power consumption (typical) |
45 W |
| Software |
|---|
| Windows operating systems supported |
Yes |
| Operational conditions |
|---|
| Operating temperature (T-T) |
5 - 40 °C |
| Operating relative humidity (H-H) |
20 - 95% |
| Weight & dimensions |
|---|
| Weight |
224 g |
| Width |
150 mm |
| Depth |
80 mm |
| Height |
32 mm |
| Package weight |
728 g |
| Package width |
214 mm |
| Package depth |
182 mm |
| Package height |
64 mm |
| Design |
|---|
| Windows operating systems supported |
Yes |
| Product colour |
Black |
| Certification |
FCC/ICES
CE
KCC
RCM
BSMI
VCCI
CB
UL+cUL
EAC
TUV
Mark
Serbia Kvalitet
South Africa SABS&LoA
Israel SII
Ukraine DoC |
| Packaging data |
|---|
| Package weight |
728 g |
| Package width |
214 mm |
| Package depth |
182 mm |
| Package height |
64 mm |
| Certificates |
|---|
| Certification |
FCC/ICES
CE
KCC
RCM
BSMI
VCCI
CB
UL+cUL
EAC
TUV
Mark
Serbia Kvalitet
South Africa SABS&LoA
Israel SII
Ukraine DoC |
| Logistics data |
|---|
| Harmonized System (HS) code |
84733020 |
