Description
4K 30 fps, 8MP 3840 x 2160 (16:9), PoE, 10/100 MbE RJ45, IP66, IK10, 9.25W, white
Description
All-weather, vandal-proof 4K PoE camera with a 1/1.8" 8MP image sensor, Multi-TOPS AI Engine, and long-range IR night vision ideal for discreet installations in high-traffic areas.Specifications
| Performance | |
|---|---|
| Infrared (IR) cut-off filter | Yes |
| Processor model | ARM Cortex-A53 |
| Type | IP security camera |
| Connectivity technology | Wired |
| Placement supported | Indoor & outdoor |
| Built-in processor | Yes |
| Design | |
| Weatherproof | Yes |
| IK code | IK10 |
| Form factor | Dome |
| Product colour | White |
| Mounting type | Ceiling/wall |
| Protection features | Tamper resistant, Vandal proof |
| LED indicators | Yes |
| International Protection (IP) code | IP66 |
| Housing material | Aluminium, Polycarbonate (PC) |
| Camera | |
| Lens viewing angle, horizontal | 109.9° |
| Lens viewing angle, vertical | 56.7° |
| Lens viewing angle, diagonal | 134.1° |
| Image sensor | |
| Optical sensor size | 25.4 / 1.8 mm (1 / 1.8") |
| Night vision | |
| Night vision | Yes |
| Night vision distance | 30 m |
| LED type | IR |
| Video | |
| Noise reduction | Yes |
| Image quality adjustment | Brightness, Contrast, HDR, Sharpness |
| Text caption overlay | Yes |
| Privacy masking | Yes |
| Noise reduction technology | 2D noise reduction, 3D noise reduction |
| Maximum resolution | 3840 x 2160 pixels |
| Frame rate | 30 fps |
| Total megapixels | 8 MP |
| Audio | |
| Built-in microphone | Yes |
| Network | |
| Bluetooth | No |
| Ethernet interface type | Fast Ethernet |
| Ethernet LAN | Yes |
| Wi-Fi | No |
| Storage | |
| Built-in HDD | No |
| Ports & interfaces | |
| Ethernet LAN (RJ-45) ports | 1 |
| Connectivity technology | Wired |
| Security | |
| Light sensor | Yes |
| Human and vehicle targets classification | Yes |
| Management features | |
| Reset button | Yes |
| Power | |
| Power source type | PoE |
| Power consumption (max) | 9.25 W |
| DC output voltage | 37, 42.5, 48, 54, 57 |
| Operational conditions | |
| Operating temperature (T-T) | -30 - 50 °C |
| Operating relative humidity (H-H) | 0 - 90% |
| Weight & dimensions | |
| Height | 96.3 mm |
| Diameter | 14.5 cm |
| Weight | 820 g |
| Features | |
| License plate recognition | Yes |
| Sustainability | |
| Compliance certificates | CE, Federal Communications Commission (FCC), Industry Canada (IC), National Defense Authorization Act (NDAA) |
| Packaging content | |
| Number of cameras | 1 |
| Screws included | Yes |
| Mounting kit | Yes |
| Manual | Yes |
| Technical details | |
| Compliance certificates | CE, Federal Communications Commission (FCC), Industry Canada (IC), National Defense Authorization Act (NDAA) |
