Description
UGREEN NASync DXP6800 Pro 6-Bay Desktop NAS
.Dual 10GbE Network Ports: Two 10GbE high-speed network ports that can be aggregated into 20G bandwidth for download speeds of up to 2500MB/s. Transfer large files smoothly like a breeze. Load between the two port links can be dynamically adjusted and balanced to improve transmission efficiency.
.Unparalleled Processing Performance: With a 12th Gen, 10-core 12-thread Intel Core i5 Processor, processing performance is improved by leaps and bounds compared to previous processors.
.6-Bay, 196TB Massive Data Storage: Equipped with six SATA and two M.2 NVMe drive bays, the NASync DXP6800 Pro has a maximum storage capacity of up to 196TB. And supports JBOD/Basic/RAID0/RAID1/RAID5/RAID6/RAID10 RAID levels. Store thousands of HD movies, pictures, and documents, Making NASync a movie library, photo album, and file storage space all in one.
.One, All-Inclusive App: Rather than downloading individual applications for specific functions, the NAS App incorporates these functions into one place. Access Storage Manager, Files, Photos, and more, all from one convenient location. (Please follow the instructions to upgrade the firmware for a better experience.)
.Professional Data Security: Compared with cloud drives, NASync allows users to store massive personal data in trusted local devices, preventing leakage and surveillance to the greatest extent. Data transmission and accounts can be fully protected with professional encryption and multi-factor authentication.
Key Features
- Brand UGREEN
- Material Metal
- Mounting type Tabletop
- Assembly required No
- Weight capacity Minimum weight: 3 kg
Description
About this item.Dual 10GbE Network Ports: Two 10GbE high-speed network ports that can be aggregated into 20G bandwidth for download speeds of up to 2500MB/s. Transfer large files smoothly like a breeze. Load between the two port links can be dynamically adjusted and balanced to improve transmission efficiency.
.Unparalleled Processing Performance: With a 12th Gen, 10-core 12-thread Intel Core i5 Processor, processing performance is improved by leaps and bounds compared to previous processors.
.6-Bay, 196TB Massive Data Storage: Equipped with six SATA and two M.2 NVMe drive bays, the NASync DXP6800 Pro has a maximum storage capacity of up to 196TB. And supports JBOD/Basic/RAID0/RAID1/RAID5/RAID6/RAID10 RAID levels. Store thousands of HD movies, pictures, and documents, Making NASync a movie library, photo album, and file storage space all in one.
.One, All-Inclusive App: Rather than downloading individual applications for specific functions, the NAS App incorporates these functions into one place. Access Storage Manager, Files, Photos, and more, all from one convenient location. (Please follow the instructions to upgrade the firmware for a better experience.)
.Professional Data Security: Compared with cloud drives, NASync allows users to store massive personal data in trusted local devices, preventing leakage and surveillance to the greatest extent. Data transmission and accounts can be fully protected with professional encryption and multi-factor authentication.
Specifications
| Storage | |
|---|---|
| Online RAID migration | Yes |
| Online RAID expansion | Yes |
| Bad block scan | Yes |
| Auto-rebuild | Yes |
| Storage drives installed | No |
| Maximum supported storage capacity | 196 TB |
| RAID support | Yes |
| Supported file systems | BTRFS, FAT32, HFS+, NTFS, exFAT, ext4 |
| RAID levels | 0, 1, 5, 6, 10, JBOD |
| Storage drive sizes supported | 2.5,3.5,M.2 |
| Number of M.2 (M & B) slots | 2 |
| RAID rebuild | Yes |
| Total installed system drives capacity | 128 GB |
| System drive type | SSD |
| Processor | |
| Processor manufacturer | Intel |
| Processor threads | 12 |
| Processor frequency | 4.4 GHz |
| Processor family | Intel® Core™ i5 |
| Processor model | i5-1235U |
| Processor cores | 10 |
| Memory | |
| Internal memory type | DDR5 |
| Internal memory | 8 GB |
| Maximum RAM supported | 64 GB |
| Memory slots | 2 |
| Memory form factor | SO-DIMM |
| Network | |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10000 Mbit/s |
| Jumbo frames support | Yes |
| iSCSI support | Yes |
| Ports & interfaces | |
| USB port | Yes |
| HDMI ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
| Thunderbolt 4 ports quantity | 1 |
| Hard drive | |
| RAID support | Yes |
| Supported file systems | BTRFS, FAT32, HFS+, NTFS, exFAT, ext4 |
| RAID levels | 0, 1, 5, 6, 10, JBOD |
| Design | |
| Country of origin | China |
| Chassis type | Desktop |
| Technical details | |
| Type | NAS |
| Device class | Small & Medium Business |
| Backup function | Yes |
| Backup features | Cloud, USB drive, iSCSI LUN |
| Card reader integrated | Yes |
| Multilingual support | Yes |
| Chassis type | Desktop |
| Buzzer | Yes |
| Warranty period | 3 year(s) |
| Performance | |
| Built-in FTP server | Yes |
| System log | Yes |
| Share folder access right management | Yes |
| S.M.A.R.T. support | Yes |
| Password authentication | Yes |
| Network Time Protocol (NTP) client | Yes |
| Disk scan | Yes |
| Remotely operated | Yes |
| Type | NAS |
| Device class | Small & Medium Business |
| Backup function | Yes |
| Backup features | Cloud, USB drive, iSCSI LUN |
| Card reader integrated | Yes |
| On/off switch | Yes |
| Web-based management | Yes |
| Operating system installed | UGOS PRO |
| Multilingual support | Yes |
| Buzzer | Yes |
| Third-party support | Yes |
| Snapshot | Yes |
| Software | |
| Operating system installed | UGOS PRO |
| Management features | |
| On/off switch | Yes |
| Web-based management | Yes |
| Power | |
| Power supply location | Built-in |
| External power adapter | Yes |
| Packaging content | |
| External power adapter | Yes |
| Logistics data | |
| Country of origin | China |
| Other features | |
| Country of origin | China |
| Warranty period | 3 year(s) |
