Description
Ultra-HD 4K, 8MP, 1/1.8-inch CMOS, 30 FPS, Wi-Fi, USB3.0 Type-B, USB2.0 Type-A, RJ-45
Smarter Meetings, One Device.
All-in-One Intelligent USB Conference Camera for Small and Huddle Rooms
MAKE YOUR MEETINGS SMARTER
With 4K ultra-HD imaging, a 120° super-wide-angle lens and Smart Area Exposure technology, the UVC40 E2 ensures exceptional video quality. AI features like Auto Framing and Speaker Tracking enhance conferencing, while 8 MEMS microphones and a high-fidelity speaker ensure excellent call quality. Manageable via Yealink Device Management Platform, UVC40 E2 is your choice for seamless collaboration.
SMART AI, CLEAR FOCUS.
With advanced AI technology such as Auto Framing and Speaker Tracking, the UVC40 E2 automatically adjusts framing based on participant count and positions, seamlessly zooms in on speakers without manual intervention, ensuring enhanced conference focus during meetings.
SMART VISION, WIDE VIEW.
Featuring a ultra-HD 4K lens, the UVC40 E2 ensures clear and smooth video calls, delivering vivid and detailed presentations. Its 120° ultra-wide view effortlessly covers every corner of the meeting room, capturing all participants. Smart Area Exposure* enhances overall brightness through AI image algorithms, ensuring optimal face and picture presentation.
Smart Sound,
Superior Clarity.
8 MEMS microphone arrays for superior noise reduction and echo cancellation. Enhanced by an upgraded beamforming algorithm and advanced acoustic processing technology, the UVC40 E2 delivers high-quality full-duplex calls with precise voice pickup.
Description
VC40 E2Smarter Meetings, One Device.
All-in-One Intelligent USB Conference Camera for Small and Huddle Rooms
MAKE YOUR MEETINGS SMARTER
With 4K ultra-HD imaging, a 120° super-wide-angle lens and Smart Area Exposure technology, the UVC40 E2 ensures exceptional video quality. AI features like Auto Framing and Speaker Tracking enhance conferencing, while 8 MEMS microphones and a high-fidelity speaker ensure excellent call quality. Manageable via Yealink Device Management Platform, UVC40 E2 is your choice for seamless collaboration.
SMART AI, CLEAR FOCUS.
With advanced AI technology such as Auto Framing and Speaker Tracking, the UVC40 E2 automatically adjusts framing based on participant count and positions, seamlessly zooms in on speakers without manual intervention, ensuring enhanced conference focus during meetings.
SMART VISION, WIDE VIEW.
Featuring a ultra-HD 4K lens, the UVC40 E2 ensures clear and smooth video calls, delivering vivid and detailed presentations. Its 120° ultra-wide view effortlessly covers every corner of the meeting room, capturing all participants. Smart Area Exposure* enhances overall brightness through AI image algorithms, ensuring optimal face and picture presentation.
Smart Sound,
Superior Clarity.
8 MEMS microphone arrays for superior noise reduction and echo cancellation. Enhanced by an upgraded beamforming algorithm and advanced acoustic processing technology, the UVC40 E2 delivers high-quality full-duplex calls with precise voice pickup.
Specifications
| Performance | |
|---|---|
| Product type | Personal video conferencing system |
| Product colour | Black |
| Signal-to-Noise Ratio (SNR) | 72 dB |
| Number of cameras | 1 |
| Auto framing | Yes |
| Technical details | |
| Product type | Personal video conferencing system |
| Product colour | Black |
| Signal-to-Noise Ratio (SNR) | 72 dB |
| Number of cameras | 1 |
| Video | |
| HD type | 4K Ultra HD |
| Megapixel (approx.) | 8 MP |
| Maximum frame rate | 30 fps |
| Audio | |
| Frequency range | 50 - 20000 Hz |
| Line-out impedance | 4 Ω |
| Speaker power | 5 W |
| Noise reduction | Yes |
| Echo cancellation | Yes |
| Built-in speaker(s) | Yes |
| Automatic gain control | Yes |
| Audio Lip synchronization | Yes |
| Audio system full duplex | Yes |
| Ports & interfaces | |
| DC-in jack | Yes |
| USB 2.0 ports quantity | 1 |
| Microphone in | Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-B ports quantity | 1 |
| Reset slot | Yes |
| Network | |
| Wi-Fi | Yes |
| Camera | |
| Sensor type | CMOS |
| Image sensor size | 1/1.8" |
| Field of view (FOV) angle | 120° |
| Megapixel (approx.) | 8 MP |
| Camera type | Single camera |
| Microphone | |
| Microphone sensitivity | -38 dB |
| Number of microphones | 8 |
| Number of microphone arrays | 1 |
| Features | |
| Cable lock slot | Yes |
| Computer system | |
| Windows operating systems supported | Yes |
| Mac operating systems supported | Yes |
| Operational conditions | |
| Storage temperature (T-T) | -30 - 70 °C |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 10 - 95% |
| Power | |
| AC input voltage | 100 - 240 V |
| Power source type | AC |
| DC output voltage | 48 V |
| DC output current | 0.7 A |
| Weight & dimensions | |
| Width | 600 mm |
| Depth | 68 mm |
| Height | 82 mm |
| Weight | 1.37 kg |
| Packaging content | |
| Mounting kit | Yes |
| Remote control included | Yes |
| Cables included | USB |
| AC adapter included | Yes |
| Quick start guide | Yes |
