Description
Industrial Wireless Barcode Scanner, CMOS, IP54, Bluetooth 5.1
Equipped with a professional scan engine, it can accurately and rapidly read 1D/2D barcodes
and every type of direct part mark (DPM) codes -- including the most challenging mark,
dot peen, as well as laser etch, ink mark, and chemical etch.
Dual-Color Variable lllumination
Switchable lighting system in red and white. Automatically adjust it based on barcode types
and surface including low-contrast, reflective, curves and different backgrounds.
Wireless Connectivity for Scanning Freedom
Equipped with Bluetooth 5.1, allowing users to easily scan barcodes from eveywhere
in the workplace without being limited by the length of the cords. The wireless communication
range of up to 100 meters, mostly enhancing flexibility and productivity.
High-Capacity Battery for a Full Shift
Available in a high-capacity 3200mAh battery and a charging cradle, K220 delivers
up to 25 hours of continuous scanning and supports 40,000 scans on a single charge
Workers can count on a non-stop, full-shift power supply.
Triple Scanning Feedback Modes
Real-time scanning feedback through vibration motor, buzzer, and LED reminder
ensuring clear feedback even in noisy environments.
Ultra-Rugged Design
Built with durable ABS and TPU materials for enhanced shock resistance,
this device withstands drops of up to 1.8 meters. lt features lP54-rated dust-and-water-proof
making it resilient in harsh environments.
Description
High-Performance Scanning on DPM and 1D/2D BarcodesEquipped with a professional scan engine, it can accurately and rapidly read 1D/2D barcodes
and every type of direct part mark (DPM) codes -- including the most challenging mark,
dot peen, as well as laser etch, ink mark, and chemical etch.
Dual-Color Variable lllumination
Switchable lighting system in red and white. Automatically adjust it based on barcode types
and surface including low-contrast, reflective, curves and different backgrounds.
Wireless Connectivity for Scanning Freedom
Equipped with Bluetooth 5.1, allowing users to easily scan barcodes from eveywhere
in the workplace without being limited by the length of the cords. The wireless communication
range of up to 100 meters, mostly enhancing flexibility and productivity.
High-Capacity Battery for a Full Shift
Available in a high-capacity 3200mAh battery and a charging cradle, K220 delivers
up to 25 hours of continuous scanning and supports 40,000 scans on a single charge
Workers can count on a non-stop, full-shift power supply.
Triple Scanning Feedback Modes
Real-time scanning feedback through vibration motor, buzzer, and LED reminder
ensuring clear feedback even in noisy environments.
Ultra-Rugged Design
Built with durable ABS and TPU materials for enhanced shock resistance,
this device withstands drops of up to 1.8 meters. lt features lP54-rated dust-and-water-proof
making it resilient in harsh environments.
Specifications
| Scanning | |
|---|---|
| Type | Handheld bar code reader |
| Linear (1D) barcodes supported | Codabar, Code 11, Code 128, Code 39, Code 39 (ASCII), Code 93, EAN-13, EAN-8, GS1 DataBar, GS1-128 (UCC/EAN-128), ISBN, ISBT 128, Industrial 2 of 5, Interleaved 2 of 5, MSI, MSI-Plessey, Standard 25, UPC-A, UPC-E, Matrix 2 of 5 |
| 2D (matrix & stacked) barcodes supported | Data Matrix, PDF417, QR Code |
| Working distance | 100 m |
| Wavelength | 650 nm |
| Sensor type | CMOS |
| Scanner type | 1D/2D |
| Pitch reading angle | -60 - 60° |
| Optical sensor resolution (W x H) | 1280 x 1080 pixels |
| Ports & interfaces | |
| Connectivity technology | Wireless |
| Bluetooth version | 5.1 |
| Standard interfaces | Bluetooth |
| Performance | |
| Protection features | Drop resistant, Dustproof, Shock resistant, Waterproof |
| LED indicators | Yes |
| Housing material | Acrylonitrile butadiene styrene (ABS), Thermoplastic urethane (TPU) |
| International Protection (IP) code | IP54 |
| Product colour | Black |
| Buzzer | Yes |
| Vibration function | Yes |
| Design | |
| Type | Handheld bar code reader |
| Protection features | Drop resistant, Dustproof, Shock resistant, Waterproof |
| LED indicators | Yes |
| Housing material | Acrylonitrile butadiene styrene (ABS), Thermoplastic urethane (TPU) |
| International Protection (IP) code | IP54 |
| Product colour | Black |
| Power | |
| Power source type | Battery |
| Battery life | 25 h |
| Battery capacity | 3200 mAh |
| Weight & dimensions | |
| Width | 98 mm |
| Depth | 72 mm |
| Height | 186 mm |
| Weight | 238 g |
| Technical details | |
| Type | Handheld bar code reader |
| Protection features | Drop resistant, Dustproof, Shock resistant, Waterproof |
| LED indicators | Yes |
| Housing material | Acrylonitrile butadiene styrene (ABS), Thermoplastic urethane (TPU) |
| International Protection (IP) code | IP54 |
| Product colour | Black |
| Buzzer | Yes |
| Operational conditions | |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating temperature (T-T) | -20 - 50 °C |
| Operating relative humidity (H-H) | 5 - 95% |
