Acer Home H6546, 5200 ANSI lumens, DLP, 1080p (1920x1080), 10000:1, 16:9, 4:3
Description
Acer Home H6546. Projector brightness: 5200 ANSI lumens, Projection technology: DLP, Projector native resolution: 1080p (1920x1080). Light source type: Lamp, Service life of light source: 5000 h, Service life of light source (economic mode): 10000 h. Focus: Manual, Focal length range: 21.8 - 24 mm, Aperture range (F-F): 2.5 - 2.67. Serial interface type: RS-232, HDMI version: 1.4b. Noise level: 27 dB
Specifications
| Projector |
|---|
| Projector native resolution |
1080p (1920x1080) |
| Native aspect ratio |
16:9 |
| Supported aspect ratios |
4:3 |
| Contrast ratio (typical) |
10000:1 |
| Zoom ratio |
1.1:1 |
| Keystone correction, vertical |
+/-40° |
| Projection technology |
DLP |
| Projector brightness |
5200 ANSI lumens |
| Zoom type |
Manual |
| Lamps |
|---|
| Lamp type |
OSRAM |
| Lamp power |
240 W |
| Light source type |
Lamp |
| Service life of light source |
5000 h |
| Service life of light source (economic mode) |
10000 h |
| Light source |
|---|
| Lamp type |
OSRAM |
| Lamp power |
240 W |
| Light source type |
Lamp |
| Service life of light source |
5000 h |
| Service life of light source (economic mode) |
10000 h |
| Lens system |
|---|
| Zoom ratio |
1.1:1 |
| Focus |
Manual |
| Focal length range |
21.8 - 24 mm |
| Aperture range (F-F) |
2.5 - 2.67 |
| Throw ratio |
1.48 - 1.62 (60"@2m) |
| Zoom type |
Manual |
| Video |
|---|
| Full HD |
Yes |
| 3D |
Yes |
| Audio |
|---|
| Built-in speaker(s) |
Yes |
| Number of built-in speakers |
1 |
| RMS rated power |
3 W |
| Ports & interfaces |
|---|
| DC-in jack |
Yes |
| HDMI version |
1.4b |
| VGA (D-Sub) ports quantity |
0 |
| HDMI ports quantity |
2 |
| Composite video in |
0 |
| Audio (L/R) in |
1 |
| Audio (L/R) out |
1 |
| Serial interface type |
RS-232 |
| Component video (YPbPr/YCbCr) in |
0 |
| Storage |
|---|
| Card reader integrated |
No |
| Sound emission |
|---|
| Noise level |
27 dB |
| Technical details |
|---|
| DC-in jack |
Yes |
| Product colour |
White |
| Lamp power |
240 W |
| Performance |
|---|
| Noise level |
27 dB |
| Features |
|---|
| Noise level |
27 dB |
| Multimedia |
|---|
| Built-in speaker(s) |
Yes |
| Number of built-in speakers |
1 |
| RMS rated power |
3 W |
| Design |
|---|
| Product colour |
White |
| Display |
|---|
| Built-in display |
No |
| Power |
|---|
| AC input voltage |
100 - 240 V |
| Power source |
AC |
| Power consumption (typical) |
240 W |
| Power consumption (standby) |
0.5 W |
| Weight & dimensions |
|---|
| Weight |
2.8 kg |
| Width |
313 mm |
| Depth |
236 mm |
| Height |
113.7 mm |
