Acer M311, 4500 ANSI lumens, WXGA (1280x800), 20000:1, 16:10, 0 - 7620 mm (0 - 300"), 4:3, 16:9
Description
Acer M311. Projector brightness: 4500 ANSI lumens, Projector native resolution: WXGA (1280x800), Contrast ratio (typical): 20000:1. Light source type: LED, Lamp power: 220 W, Lamps quantity: 1 lamp(s). Focal length range: 21.85 - 24 mm, Aperture range (F-F): 2.41 - 2.53, Throw ratio: 1,54 a 1,72 (1524 mm@2000 mm). Analog signal format system: NTSC, PAL, SECAM. Wi-Fi standards: 802.11a, 802.11ad, 802.11b, Wi-Fi 5 (802.11ac)
Specifications
| Projector |
|---|
| Number of colours |
1.07 billion colours |
| Projector native resolution |
WXGA (1280x800) |
| Native aspect ratio |
16:10 |
| Supported aspect ratios |
4:3, 16:9 |
| Screen size compatibility |
0 - 7620 mm (0 - 300") |
| Projection distance |
1 - 10 m |
| Contrast ratio (typical) |
20000:1 |
| Vertical synchronization (min) |
24 kHz |
| Keystone correction, vertical |
-40 - 40° |
| Horizontal synchronization (min) |
15 kHz |
| Horizontal synchronization (max) |
100 kHz |
| Projector brightness |
4500 ANSI lumens |
| Projection modes |
Front, Rear |
| Lamps |
|---|
| Lamps quantity |
1 lamp(s) |
| Lamp power |
220 W |
| Light source type |
LED |
| Light source |
|---|
| Lamps quantity |
1 lamp(s) |
| Lamp power |
220 W |
| Light source type |
LED |
| Lens system |
|---|
| Focal length range |
21.85 - 24 mm |
| Aperture range (F-F) |
2.41 - 2.53 |
| Throw ratio |
1,54 a 1,72 (1524 mm@2000 mm) |
| Video |
|---|
| Analog signal format system |
NTSC, PAL, SECAM |
| Full HD |
Yes |
| 3D |
Yes |
| Audio |
|---|
| Built-in speaker(s) |
Yes |
| Number of built-in speakers |
1 |
| RMS rated power |
10 W |
| Ports & interfaces |
|---|
| VGA (D-Sub) ports quantity |
1 |
| HDMI ports quantity |
0 |
| USB 2.0 ports quantity |
1 |
| Composite video in |
1 |
| Audio (L/R) in |
1 |
| Audio (L/R) out |
1 |
| DVI port |
No |
| Network |
|---|
| Smart TV |
Yes |
| Wi-Fi |
Yes |
| Wi-Fi standards |
802.11a, 802.11ad, 802.11b, Wi-Fi 5 (802.11ac) |
| Bluetooth |
Yes |
| Bluetooth version |
4.2 |
| Storage |
|---|
| Internal memory |
2 GB |
| Internal memory type |
DDR4 |
| Technical details |
|---|
| Product colour |
White |
| Internal memory type |
DDR4 |
| Internal memory |
2 GB |
| Projection modes |
Front, Rear |
| Lamp power |
220 W |
| Performance |
|---|
| Market positioning |
Home cinema |
| Processor cores |
4 |
| Internal memory |
2 GB |
| Processor model |
RK3328 |
| Processor architecture |
ARM Cortex-A53 |
| Internal memory type |
DDR4 |
| Features |
|---|
| Projection modes |
Front, Rear |
| Multimedia |
|---|
| Built-in speaker(s) |
Yes |
| Number of built-in speakers |
1 |
| RMS rated power |
10 W |
| Design |
|---|
| Market positioning |
Home cinema |
| Product type |
Standard throw projector |
| Product colour |
White |
| Display |
|---|
| Built-in display |
No |
| Power |
|---|
| AC input voltage |
120 - 230 V |
| Power source |
AC |
| Power consumption (typical) |
260 W |
| Power consumption (standby) |
0.5 W |
| Processor |
|---|
| Processor cores |
4 |
| Processor model |
RK3328 |
| Processor architecture |
ARM Cortex-A53 |
| Supplier features |
|---|
| Harmonized System (HS) code |
85286200 |
| Weight & dimensions |
|---|
| Weight |
2.7 kg |
| Width |
313 mm |
| Depth |
240 mm |
| Height |
113.7 mm |
| Logistics data |
|---|
| Harmonized System (HS) code |
85286200 |
| Other features |
|---|
| Internal memory type |
DDR4 |
