10GBase-SR SFP+ Transceiver (MMF, 850nm, 300m, LC, DOM)
Description
This HP® R9D18A compatible SFP+ transceiver provides 10GBase-SR throughput up to 300m over multi-mode fiber (MMF) using a wavelength of 850nm via an LC connector. Our transceiver is built to meet or exceed OEM specifications and is guaranteed to be 100% compatible with HP®. It has been programmed, uniquely serialized, and tested for data-traffic and application to ensure that it will initialize and perform identically. All of our transceivers comply with Multi-Source Agreement (MSA) standards to provide seamless network integration. Additional product features include Digital Optical Monitoring (DOM) support which allows access to real-time operating parameters. This transceiver is Trade Agreements Act (TAA) compliant. We stand behind the quality of our products and proudly offer a limited lifetime warranty.
Specifications
| Performance |
|---|
| SFP transceiver type |
Fiber optic |
| Ethernet LAN |
Yes |
| Digital Diagnostics Monitoring (DDM) |
Yes |
| Fiber optic connector |
LC |
| Maximum transfer distance |
300 m |
| Wavelength |
850 nm |
| Duplex system |
Full |
| Maximum data transfer rate |
10000 Mbit/s |
| Interface type |
SFP+ |
| Multi-mode fiber (MMF) supported |
Yes |
| Ethernet interface type |
10 Gigabit Ethernet |
| SFP transceiver standard |
SR |
| Copper ethernet cabling technology |
10GBASE |
| Country of origin |
United States |
| Product colour |
Stainless steel |
| Features |
|---|
| Product colour |
Stainless steel |
| Country of origin |
United States |
| Certification |
TAA, BBB, SixSigma |
| Certificates |
|---|
| Certification |
TAA, BBB, SixSigma |
| Compliance certificates |
CE, REACH, RoHS, WEEE |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 70 °C |
| Maximum operating temperature |
70 °C |
| Network |
|---|
| SFP transceiver type |
Fiber optic |
| Fiber optic connector |
LC |
| Maximum data transfer rate |
10000 Mbit/s |
| Interface type |
SFP+ |
| Ethernet interface type |
10 Gigabit Ethernet |
| Packaging content |
|---|
| Quantity per pack |
1 pc(s) |
| Technical details |
|---|
| Package width |
69.8 mm |
| Package height |
30.5 mm |
| Maximum transfer distance |
300 m |
| Wavelength |
850 nm |
| Duplex system |
Full |
| Ethernet LAN |
Yes |
| Compliance certificates |
CE, REACH, RoHS, WEEE |
| Packaging data |
|---|
| Package depth |
120.7 mm |
| Package width |
69.8 mm |
| Package height |
30.5 mm |
| Package weight |
181.437 g |
| Weight & dimensions |
|---|
| Package depth |
120.7 mm |
| Package width |
69.8 mm |
| Package height |
30.5 mm |
| Package weight |
181.437 g |
| Logistics data |
|---|
| Quantity per pack |
1 pc(s) |
| Country of origin |
United States |
