Description
640 x 480 CMOS Sensor, 5 mil, USB, 167 x 73.5 x 105.4 mm, 195 g
The Adesso NuScan 2600U is compatible with a wide range of 1D and 2D barcode symbologies. With CMOS imager the NuScan 2600U is able to scan major 2D barcodes such as PDF 417, QR Codes, Data Matrix, and micro QR Code. As your daily peripheral companion, your peripheral must be able to provide you with good hygiene and cleanness. The NuScan 2600U can be cleaned periodically. With all these great features, the NuScan 2600U is truly your ultimate barcode scanner.
2D Scanning Engine
The 2D scanning engine offers decoding capability for 2D barcodes like PDF417, Data Matrix, QR Code, MicroQR as well as common 1D barcodes.
Superior Scanning Performance
Equipped with a 640*480 CMOS sensor the scanner has a motion tolerance of 5 inches per second, offering fast and accurate scanning results.
Long Scanning Range
The scanner is able to scan barcodes up to a distance of 10 inches.
Drop Protection
The drop-protection design prevents damage due to accidental drops of less than 1.5 meters.
Description
2D Handheld Barcode Scanner (USB)The Adesso NuScan 2600U is compatible with a wide range of 1D and 2D barcode symbologies. With CMOS imager the NuScan 2600U is able to scan major 2D barcodes such as PDF 417, QR Codes, Data Matrix, and micro QR Code. As your daily peripheral companion, your peripheral must be able to provide you with good hygiene and cleanness. The NuScan 2600U can be cleaned periodically. With all these great features, the NuScan 2600U is truly your ultimate barcode scanner.
2D Scanning Engine
The 2D scanning engine offers decoding capability for 2D barcodes like PDF417, Data Matrix, QR Code, MicroQR as well as common 1D barcodes.
Superior Scanning Performance
Equipped with a 640*480 CMOS sensor the scanner has a motion tolerance of 5 inches per second, offering fast and accurate scanning results.
Long Scanning Range
The scanner is able to scan barcodes up to a distance of 10 inches.
Drop Protection
The drop-protection design prevents damage due to accidental drops of less than 1.5 meters.
Specifications
| Scanning | |
|---|---|
| Type | Handheld bar code reader |
| Yaw reading angle | -40 - 40° |
| Working distance | 50 cm |
| Wavelength | 630 nm |
| Tilt reading angle | -360 - 360° |
| Sensor type | CMOS |
| Scanner type | 2D |
| Read rate (max) | 300 reads/s |
| Pitch reading angle | -45 - 45° |
| Light levels (direct sunlight) | 0 - 100000 lx |
| Optical sensor resolution (W x H) | 640 x 480 pixels |
| Ports & interfaces | |
| Connectivity technology | Wired |
| Cable length | 1.5 m |
| Standard interfaces | USB |
| Performance | |
| Protection features | Shock resistant, Water resistant |
| LED indicators | Yes |
| Housing material | Plastic |
| Product colour | Black |
| Certification | FCC, CE, IC |
| Buzzer | Yes |
| Country of origin | China |
| Light levels (direct sunlight) | 0 - 100000 lx |
| Design | |
| Type | Handheld bar code reader |
| Protection features | Shock resistant, Water resistant |
| LED indicators | Yes |
| Housing material | Plastic |
| Product colour | Black |
| Certification | FCC, CE, IC |
| Power | |
| Power consumption | 110 mA |
| Power source type | USB |
| Input voltage | 5 V |
| Weight & dimensions | |
| Width | 94 mm |
| Depth | 68 mm |
| Height | 172 mm |
| Weight | 174 g |
| Package width | 182.9 mm |
| Package depth | 114.3 mm |
| Package height | 266.7 mm |
| Package weight | 907.19 g |
| Technical details | |
| Type | Handheld bar code reader |
| Protection features | Shock resistant, Water resistant |
| LED indicators | Yes |
| Housing material | Plastic |
| Compatible operating systems | Windows 7, Mac OS X |
| Product colour | Black |
| Certification | FCC, CE, IC |
| Buzzer | Yes |
| Harmonized System (HS) code | 84716070 |
| Compliance certificates | RoHS |
| Packaging data | |
| Package width | 182.9 mm |
| Package depth | 114.3 mm |
| Package height | 266.7 mm |
| Package weight | 907.19 g |
| Operational conditions | |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating temperature (T-T) | -20 - 50 °C |
| Operating relative humidity (H-H) | 20 - 95% |
| Storage relative humidity (H-H) | 5 - 95% |
| Light levels (direct sunlight) | 0 - 100000 lx |
| Logistics data | |
| Harmonized System (HS) code | 84716070 |
| Other features | |
| Compatible operating systems | Windows 7, Mac OS X |
