140 mm, PWM, 400 - 2800 RPM, 95.00 cfm, 12 V DC, 3-pin, 245 g
Reasons To Buy
Extremely Wide Speed Range
Building up on the success of the P14 PWM, the P14 Max extends the controllable speed to an impressively wide range from 400 rpm up to 2800 rpm. This enables a quiet operation when low airflow is needed and also an unprecedented level of performance on heatsinks and radiators. The P14 Max provides a significant performance boost to existing air and water cooling solutions.
Maximum Performance — Without Compromises
The P14 Max delivers focused airflow and high static pressure, making it suitable for all scenarios. The fan is optimised for use on radiators, heat sinks, pinholes and mesh. Therefore, the P14 Max is the ideal fan for enthusiasts and professionals who are looking for maximum performance with a long service life.
0 dB Mode — Zero rpm
The fan speed can be throttled down to standstill via PWM. This allows silent operation in IDLE and at the same time guarantees maximum performance when required. Thus, the P14 Max allows an incomparably dynamic adjustment of the speed, so that the airflow can be perfectly regulated for every case.
Improved Stability
The P14 Max features a closed fan wheel design. The advantage of this fan wheel combination is a pressure stability without compromise. In scenarios with high pressure resistances and higher speeds, the force effect is distributed uniformly over the entire fan wheel and enables low-vibration rotation while maintaining high static pressure.
Maximum Smoothness, Minimum Vibration
Even at low speeds the operating sound of the new ARCTIC motor is barely noticeable. Due to a sinus-magnetizing the new motor only creates about 5 % of the vibration from commutation of a regular DC-motor without filter. The rubber pads mounted at the corners additionally dampen the residual vibrations caused by the higher revolutions.
Virtually Silent due Fluid Dynamic Bearing
As a special feature, the P14 Max is equipped with ARCTIC's proven Hydrodynamic Bearing. This enables the virtually silent operation at low speeds that customers have been asking for. At maximum speed, brute performance is still guaranteed. Although these bearings tend to wear out, ARCTIC does not compromise on durability and still offers the 6-year warranty.
Quality You Can Rely On
To ensure the longevity of our products, we carry out long-term tests under different, sometimes very adverse conditions. In this way, we learn how we can permanently improve our products for our customers. In addition, the excellent results of long-term testing give us the assurance that our products are not only outstanding in terms of quality, but also in terms of durability. This is a certainty that we are happy to pass on to our customers, which is why we give a 6-year manufacturer's guarantee.
Description
ARCTIC’s versatile assortment of Fans is both quiet and powerful. We have the right options for any application or need, in sizes from 80 to 140 mm. Plus, our Fans are equipped with state-of-the-art engine technology, innovative fan blades and high-quality bearings, making them particularly durable and efficient.
Specifications
| Performance |
|---|
| Suitable location |
Computer case |
| Fan connector |
4-pin |
| Pulse-width modulation (PWM) support |
Yes |
| Rotational speed (min) |
400 RPM |
| Rotational speed (max) |
2800 RPM |
| Bearing type |
Fluid Dynamic Bearing (FDB) |
| Type |
Fan |
| Operating temperature (T-T) |
0 - 40 °C |
| Fan diameter |
14 cm |
| Supported processor sockets |
Not supported |
| Compatible processor series |
Not supported |
| Maximum airflow |
95 cfm |
| Maximum air pressure |
4.18 mmH2O |
| Airflow |
161.4 m³/h |
| Number of fans |
1 fan(s) |
| Number of fan blades |
5 |
| Design |
|---|
| Fan connector |
4-pin |
| Number of fans |
1 fan(s) |
| Product colour |
Black |
| Cable length |
0.4 m |
| Number of fan blades |
5 |
| Technical details |
|---|
| Type |
Fan |
| Fan diameter |
14 cm |
| Supported processor sockets |
Not supported |
| Compatible processor series |
Not supported |
| Maximum airflow |
95 cfm |
| Maximum air pressure |
4.18 mmH2O |
| Airflow |
161.4 m³/h |
| Number of fans |
1 fan(s) |
| Cable length |
0.4 m |
| Fan connector |
4-pin |
| Ports & interfaces |
|---|
| Fan connector |
4-pin |
| Power |
|---|
| Starting voltage |
3.9 V |
| Voltage |
12 V |
| Rated current |
0.35 A |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 40 °C |
| Colour |
|---|
| Product colour |
Black |
| Weight & dimensions |
|---|
| Package depth |
167 mm |
| Package width |
167 mm |
| Package height |
34 mm |
| Width |
140 mm |
| Package weight |
303 g |
| Depth |
140 mm |
| Height |
27 mm |
| Weight |
254 g |
| Cable length |
0.4 m |
| Packaging data |
|---|
| Package depth |
167 mm |
| Package width |
167 mm |
| Package height |
34 mm |
| Package weight |
303 g |
| Package type |
Box |
| Packaging content |
|---|
| Screws included |
Yes |
| Number of screws |
4 |
| Package type |
Box |
