Description
RS300-E12-RS4 in an Intel Xeon E-2400 and Intel Xeon 6300 1U server with support for four DDR5 ECC UDIMM, four NVMe, one M.2, one PCIe 5.0 slot and one PCIe 4.0 slot, plus dual LAN, 80 PLUS Platinum redundant power supplies, Intel Platform Firmware Resilience (PFR), onboard ASUS ASMB11-iKVM and chassis-intrusion alert.
Designed for small- to medium-sized businesses (SMBs) and cloud-service providers, offering robust and secure solutions. These processors support up to eight cores and 16 threads, with a maximum frequency of 5.6 GHz and a 95 W TDP, ensuring rapid data processing and application responsiveness. They support up to 128 GB of DDR5 4400 MT/s memory (Intel Xeon E-2400) or up to 4800 MT/s memory (Intel Xeon 6300) and PCIe 5.0 interfaces, providing server-grade 24/7 reliability for business-critical services and customer data, and cost-effective performance for entry-level bare-metal cloud services.
Key Features
- Powered by eight-core Intel Xeon E-2400-series and Intel Xeon 6300 series processor with support for up to 95 W TDP
- Four 3.5-inch or 2.5-inch hot-swap drives on front panel and one M.2 to enable extensive storage
- Up to one PCIe 5.0 slots and one PCIe 4.0 proprietary slot to drive higher bandwidth
- High power efficiency with redundant 450 W 80 PLUS Platinum power supplies
- Dual Intel I210-AT gigabit Ethernet with teaming support
- Onboard ASUS ASMB11-iKVM for out-of-band management with ASPEED AST2600 controller
- Integrated PFR FPGA as the platform Root-of-Trust solution for firmware resiliency
- Chassis-intrusion for enhanced physical security
Description
Intel Xeon E-2400 processors/Intel Xeon 6300 processorsDesigned for small- to medium-sized businesses (SMBs) and cloud-service providers, offering robust and secure solutions. These processors support up to eight cores and 16 threads, with a maximum frequency of 5.6 GHz and a 95 W TDP, ensuring rapid data processing and application responsiveness. They support up to 128 GB of DDR5 4400 MT/s memory (Intel Xeon E-2400) or up to 4800 MT/s memory (Intel Xeon 6300) and PCIe 5.0 interfaces, providing server-grade 24/7 reliability for business-critical services and customer data, and cost-effective performance for entry-level bare-metal cloud services.
Specifications
| Hard drive | |
|---|---|
| Hot-swap HDD bays | Yes |
| Processor | |
| Processor socket | LGA 1700 |
| Number of processors supported | 1 |
| Design | |
| 80 PLUS certification | 80 PLUS Platinum |
| LED indicators | Power, Reset, HDD |
| Product colour | Silver |
| Chassis type | Rack (1U) |
| Memory | |
| Supported RDIMM clock speeds | 4400,4000,3600 MHz |
| Supported memory types | DDR5-SDRAM |
| Supported DIMM module capacities | 8GB, 16GB, 32GB |
| Number of DIMM slots | 4 |
| Maximum internal memory | 128 GB |
| Memory channels | Dual-channel |
| Storage | |
| Number of storage drives supported | 8 |
| Number of 3.5" bays | 4 |
| Supported storage drive interfaces | M.2, Serial ATA III, Serial Attached SCSI (SAS) |
| Hot-swap HDD bays | Yes |
| Storage drive sizes supported | 3.5" |
| Supported storage drive types | HDD & SSD |
| Network | |
| Ethernet LAN | Yes |
| Ports & interfaces | |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 3 |
| Number of SATA III connectors | 8 |
| VGA (D-Sub) ports quantity | 1 |
| USB 2.0 ports quantity | 0 |
| Ethernet LAN (RJ-45) ports | 1 |
| COM ports quantity | 1 |
| Expansion slots | |
| PCI Express x16 (Gen 5.x) slots | 1 |
| Technical details | |
| Number of storage drives supported | 8 |
| Number of 3.5" bays | 4 |
| Chassis type | Rack (1U) |
| Colour | |
| Product colour | Silver |
| Indication | |
| LED indicators | Power, Reset, HDD |
| Power | |
| Power supply | 450 W |
| 80 PLUS certification | 80 PLUS Platinum |
| Operational conditions | |
| Storage temperature (T-T) | -40 - 70 °C |
| Storage relative humidity (H-H) | 20 - 90% |
| Operating temperature (T-T) | 10 - 35 °C |
| Weight & dimensions | |
| Width | 497 mm |
| Weight | 15.2 kg |
| Height | 44 mm |
| Depth | 439.5 mm |
