Camera Station S2108 (EU), 2 TB HDD, Intel® Celeron, 128GB SSD, 8GB Memory, 8 licenses, USB 3.0, 8 PoE ports
Key Features
- AXIS Camera Station licenses included; All-in-one solution with integrated PoE switch; Ease of installation; Ideal for basic surveillance needs; Validated with extensive support
Description
This affordable, all-in-one appliance includes a VMS client/server, storage, and an integrated PoE switch—all validated to meet the demands for reliable, basic surveillance up to 1080p. Designed to fit almost everywhere, AXIS S2108 is one of the most compact recorders on the market. It comes preloaded with AXIS Camera Station and preconfigured software licenses, so out-of-the-box you get seamless and reliable integration to all your Axis network cameras. Extensively tested with a wide range of Axis products, this smart appliance is easy to install, use, and maintain. Furthermore, it includes an advanced replacement service and a 5-year hardware warranty.
Specifications
| Performance |
|---|
| Video input channels |
8 channels |
| Maximum resolution |
1920 x 1080 pixels |
| Built-in processor |
Yes |
| Internal memory |
8192 MB |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Operating system installed |
Windows 10 IoT Enterprise |
| Networking standards |
IEEE 802.3at |
| Number of simultaneously playbacked channels |
9 channels |
| Video recording modes |
720p, 1080p |
| Wireless LAN features |
|---|
| Wi-Fi |
No |
| Hard drive |
|---|
| Number of HDDs supported |
1 |
| Total installed storage capacity |
2 TB |
| RAID support |
No |
| Number of HDDs installed |
1 |
| HDD capacity |
2 TB |
| Storage |
|---|
| Number of HDDs supported |
1 |
| Total installed storage capacity |
2 TB |
| RAID support |
No |
| Number of HDDs installed |
1 |
| HDD capacity |
2 TB |
| Ports & interfaces |
|---|
| Ethernet LAN (RJ-45) ports |
10 |
| Power over Ethernet (PoE) |
Yes |
| USB 2.0 ports quantity |
2 |
| Line-in |
Yes |
| Audio output |
1 |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
1 |
| Power over Ethernet (PoE) ports quantity |
8 |
| Networking standards |
IEEE 802.3at |
| HDMI ports quantity |
1 |
| Storage relative humidity (H-H) |
10 - 90% |
| Features |
|---|
| LED indicators |
HDD, PoE |
| Product colour |
Black |
| Brand compatibility |
Axis |
| Processor |
|---|
| Built-in processor |
Yes |
| Power |
|---|
| Power |
180 W |
| Output current |
2.3 A |
| Power consumption (typical) |
27 W |
| AC input voltage |
100 - 240 V |
| AC input frequency |
50/60 Hz |
| Power consumption (max) |
30 W |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 40 °C |
| Operating relative humidity (H-H) |
10 - 90% |
| Storage relative humidity (H-H) |
10 - 90% |
| Technical details |
|---|
| Compliance certificates |
RoHS |
| Weight & dimensions |
|---|
| Width |
310 mm |
| Depth |
230 mm |
| Height |
44 mm |
| Weight |
3.5 kg |
| Packaging content |
|---|
| Quick installation guide |
Yes |
| Cables included |
AC |
| AC adapter included |
Yes |
