Description
Box, 2 MP, 1920 x 1080, IP40, Two-way audio, PoE
Ensure privacy and security
This fully featured camera is designed with privacy and security in mind. Axis Edge Vault, a hardware-based cybersecurity platform, safeguards the device and protects sensitive information from unauthorized access. And it offers FIPS 140-3 Level 3 certified, secure cryptographic key storage and operations. A tally LED indicates video streaming or recording. And, with AXIS Live Privacy Shield, it’s easy to remotely monitor activities while protecting privacy. Furthermore, AXIS TM1903 Privacy Cover is available as an accessory to temporarily protect privacy when needed. Plus, a built-in pencil privacy filter ensures discreet images that safeguard privacy.
AI-powered analytics
AXIS M1075-L Mk II includes a deep learning processing unit (DLPU) to run advanced features and powerful analytics on the edge. With AXIS Object Analytics preinstalled, it can detect, track, and count humans. It also includes AXIS Audio Analytics, which detects sounds such as breaking glass, screams, shouts, speech, and coughing fits, and provides instant alerts when these events occur. In addition, generated metadata can be gathered and visualized in a dashboard for valuable insights.
Extended possibilities
This compact camera supports PoE and includes a USB and I/O port for optional Wi-Fi-dongle connectivity. The I/O port also allows you to connect external devices, such as a panic button - ideal in elderly care facilities and small stores. It can be mounted in corners for complete coverage with a 103° field of view and features a built-in speaker and dual microphones. Plus, voice enhancer ensures great two-way audio communication. With an IR-corrected lens, it offers professional-quality video both day and night. What’s more, a passive infrared (PIR) sensor can detect movement in total darkness. And an HDMI port lets you display live video on a public viewing monitor.
Key Features
- Day-and-night with IR illumination
- Built-in privacy features
- PIR Sensor for motion detection
- AXIS Audio Analytics on the edge
- Two-way audio communication
Description
Ideal for residential care and small stores, this compact, easy-to-install camera offers two-way audio and great image quality - around the clock. AI-powered, it supports advanced features and powerful video and audio analytics on the edge.Ensure privacy and security
This fully featured camera is designed with privacy and security in mind. Axis Edge Vault, a hardware-based cybersecurity platform, safeguards the device and protects sensitive information from unauthorized access. And it offers FIPS 140-3 Level 3 certified, secure cryptographic key storage and operations. A tally LED indicates video streaming or recording. And, with AXIS Live Privacy Shield, it’s easy to remotely monitor activities while protecting privacy. Furthermore, AXIS TM1903 Privacy Cover is available as an accessory to temporarily protect privacy when needed. Plus, a built-in pencil privacy filter ensures discreet images that safeguard privacy.
AI-powered analytics
AXIS M1075-L Mk II includes a deep learning processing unit (DLPU) to run advanced features and powerful analytics on the edge. With AXIS Object Analytics preinstalled, it can detect, track, and count humans. It also includes AXIS Audio Analytics, which detects sounds such as breaking glass, screams, shouts, speech, and coughing fits, and provides instant alerts when these events occur. In addition, generated metadata can be gathered and visualized in a dashboard for valuable insights.
Extended possibilities
This compact camera supports PoE and includes a USB and I/O port for optional Wi-Fi-dongle connectivity. The I/O port also allows you to connect external devices, such as a panic button - ideal in elderly care facilities and small stores. It can be mounted in corners for complete coverage with a 103° field of view and features a built-in speaker and dual microphones. Plus, voice enhancer ensures great two-way audio communication. With an IR-corrected lens, it offers professional-quality video both day and night. What’s more, a passive infrared (PIR) sensor can detect movement in total darkness. And an HDMI port lets you display live video on a public viewing monitor.
Specifications
| Performance | |
|---|---|
| Infrared (IR) cut-off filter | Yes |
| Processor model | Ambarella CV25 |
| Type | IP security camera |
| Connectivity technology | Wired |
| Placement supported | Indoor |
| Wide Dynamic Range (WDR) | Yes |
| Day/night mode | Yes |
| Alarm input/output | Yes |
| People counting function | Yes |
| Built-in processor | Yes |
| Dynamic range | 120 dB |
| Design | |
| Form factor | Box |
| Product colour | White |
| Mounting type | Ceiling/wall |
| LED indicators | Yes |
| International Protection (IP) code | IP40 |
| Housing material | Aluminium, Plastic |
| Camera | |
| Minimum illumination | 0.18 lx |
| Camera shutter speed | 1/19000 - 1/5 s |
| Camera pixel size | 2.8 µm |
| Lens viewing angle, horizontal | 103° |
| Lens viewing angle, vertical | 55° |
| Progressive scan | Yes |
| Image sensor | |
| Sensor type | CMOS |
| Progressive scan | Yes |
| Optical sensor size | 25.4 / 2.9 mm (1 / 2.9") |
| Lens system | |
| Maximum aperture number | 2 |
| Detect distance | 42 m |
| Observe distance | 16 m |
| Recognize distance | 8 m |
| Identify distance | 4 m |
| Zoom capability | Yes |
| Fixed focal length | 3.16 mm |
| Night vision | |
| Night vision | Yes |
| Night vision distance | 18 m |
| LED type | IR |
| Infra-red wavelength | 850 nm |
| Video | |
| Image quality adjustment | Saturation, Contrast, Brightness, Sharpness, White balance |
| Video compression formats | H.264H, H.264M, H.265 |
| Maximum resolution | 1920 x 1080 pixels |
| Frame rate | 30 fps |
| Video streaming | Yes |
| Total megapixels | 2 MP |
| Video recording | Yes |
| Audio | |
| Built-in speaker(s) | Yes |
| Built-in microphone | Yes |
| Audio system | 2-way |
| Audio formats supported | AAC-LC, LPCM, G.711, PCM, ADPCM, OPUS |
| Network | |
| Bluetooth | Yes |
| Ethernet interface type | Fast Ethernet |
| Networking standards | IEEE 802.1x, IEEE 802.1AE, IEEE 802.1ar, IEEE 802.3af, IEEE 802.3at |
| Quality of Service (QoS) support | Yes |
| Ethernet LAN | Yes |
| Wi-Fi | No |
| Storage | |
| Card reader integrated | Yes |
| Built-in HDD | No |
| Compatible memory cards | MicroSD (TransFlash) |
| Flash memory | 1024 MB |
| RAM capacity | 2048 MB |
| Ports & interfaces | |
| Terminal block port | Yes |
| HDMI ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| Connectivity technology | Wired |
| Security | |
| Video motion detection | Yes |
| HTTPS encryption | Yes |
| Active tampering alarm | Yes |
| Alarm input channels | 1 |
| Alarm output channels | 1 |
| Network access storage (NAS) | Yes |
| Management features | |
| Cloud-managed | Yes |
| Power | |
| Power source type | PoE |
| Power consumption (max) | 12.95 W |
| Power consumption (typical) | 5.4 W |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 35 °C |
| Storage temperature (T-T) | -40 - 65 °C |
| Operating relative humidity (H-H) | 10 - 85% |
| Storage relative humidity (H-H) | 5 - 95% |
| Weight & dimensions | |
| Width | 60 mm |
| Depth | 93 mm |
| Height | 105 mm |
| Weight | 153 g |
| Packaging content | |
| Number of cameras | 1 |
| Mounting kit | Yes |
| Manual | Yes |
| Other features | |
| Video compression formats | H.264H, H.264M, H.265 |
