Description
SYSTEM 2 - I-Beam / Girder Mount for Ø50mm Poles
Key Features
- Adjustable I-Beam (girder) mount for use with 50mm poles
- Cable management
- Supplied with safety bolt for secure installation
- Locking bolt included to securely set the pole vertical at any angle up to 40°
- Fits I-Beams and thick steel from 80mm (3.1") - 250mm (9.8") in width
- POLE SOLD SEPARATELY
Description
The BT7017 enables the suspension of pole mounted solutions up to 140kg from I-Beam girders. Compatible with B-Tech’s range of BT7850 ?50mm poles the locking bolt securely sets the pole vertically at any angle up to 36 degrees.
• Adjustable I-Beam (girder) mount for use with 50mm poles
• Locking bolt included to securely set the pole vertical at any angle up to 40?
• Fits I-Beams and thick steel from 80mm (3.1) - 250mm (9.8) in width
• Integrated cable management
| Features | |
|---|---|
| Bracket Type | Column |
| Colour | Black |
Specifications
| Mounting | |
|---|---|
| Width adjustment range | 80 - 250 mm |
| Product type | Clamp |
| Maximum weight capacity | 140 kg |
| Tilt angle range | -40 - 40° |
| Product colour | Black |
| Features | |
| Width adjustment range | 80 - 250 mm |
| Product type | Clamp |
| Maximum weight capacity | 140 kg |
| Tilt angle range | -40 - 40° |
| Product colour | Black |
| Housing material | Steel |
| Cable management | Yes |
| Technical details | |
| Width adjustment range | 80 - 250 mm |
| Product colour | Black |
| Maximum weight capacity | 140 kg |
| Tilt angle range | -40 - 40° |
| Colour | |
| Product colour | Black |
| Packaging content | |
| Quantity per pack | 1 pc(s) |
| Logistics data | |
| Harmonized System (HS) code | 83024200 |
