Description
Direct thermal, 100mm/sec, 203 dpi, Serial, USB v2.0 FS, Bluetooth 4.1, 2600 mAh, 1.8m, IP54, Black
- Easy to grip: 30% lighter and 26% slimmer
- than SPP-R300
- One touch cover open and easy paper loading
Mobile Field-Work Optimization
- Wireless and wired connectivity options including Bluetooth, WiFi, USB and Serial
- Supporting Easy Bluetooth Pairing™ via embedded NFC tag enabling auto pairing
- Dual-band WLAN (5GHz and 2.4 GHz)
- Dual-mode Bluetooth V4.1 Classic (MFi AP2 certified) and LE
- IP54 (Printer only) water and dust proof
- 1.8 m / 6 ft. drop rate
- Long-lasting battery life (24-hour stand by time)
Built for Multi-Purpose
- Fast printing speed up to 100 mm/sec (Receipt)
- Designed for the receipt and label printing(Simple to switch via the feed button)
- Optional linerless label printing(80 mm/sec at 203dpi)
- Supports black mark reflective sensor and transmissive gap sensor (Optional Positioning)
Description
Smaller and Lighter Design- Easy to grip: 30% lighter and 26% slimmer
- than SPP-R300
- One touch cover open and easy paper loading
Mobile Field-Work Optimization
- Wireless and wired connectivity options including Bluetooth, WiFi, USB and Serial
- Supporting Easy Bluetooth Pairing™ via embedded NFC tag enabling auto pairing
- Dual-band WLAN (5GHz and 2.4 GHz)
- Dual-mode Bluetooth V4.1 Classic (MFi AP2 certified) and LE
- IP54 (Printer only) water and dust proof
- 1.8 m / 6 ft. drop rate
- Long-lasting battery life (24-hour stand by time)
Built for Multi-Purpose
- Fast printing speed up to 100 mm/sec (Receipt)
- Designed for the receipt and label printing(Simple to switch via the feed button)
- Optional linerless label printing(80 mm/sec at 203dpi)
- Supports black mark reflective sensor and transmissive gap sensor (Optional Positioning)
Specifications
| Printing | |
|---|---|
| Type | POS printer |
| Print technology | Direct thermal |
| Print speed | 100 mm/sec |
| Maximum resolution | 203 x 203 DPI |
| Character size | 12 x 24 mm |
| Performance | |
| Type | POS printer |
| Print technology | Direct thermal |
| Print speed | 100 mm/sec |
| Maximum resolution | 203 x 203 DPI |
| Character size | 12 x 24 mm |
| Built-in barcodes | 1D, 2D, AZTECCODE, CODABAR (NW-7), Code 39, Code 93, Code-128 Codabar Library, Data Matrix, EAN13, EAN8, GS1 DataBar, ITF, MaxiCode, PDF417, QR Code, UPC-A, UPC-E |
| Paper handling | |
| Supported paper width | 80 mm |
| Maximum roll diameter | 5 cm |
| Maximum printing width | 7.2 cm |
| Ports & interfaces | |
| Standard interfaces | USB 2.0 |
| Connectivity technology | Wired & Wireless |
| USB 2.0 ports quantity | 1 |
| Bluetooth version | 4.1 |
| Bluetooth | Yes |
| USB port | Yes |
| Network | |
| Ethernet LAN | No |
| Wi-Fi | Yes |
| Wi-Fi standards | 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| Print technology | |
| Type | POS printer |
| Print technology | Direct thermal |
| Print speed | 100 mm/sec |
| Character size | 12 x 24 mm |
| Print quality | |
| Maximum resolution | 203 x 203 DPI |
| Maximum printing width | 7.2 cm |
| Technical details | |
| Maximum printing width | 7.2 cm |
| Magnetic stripe reader | Yes |
| Product colour | Black |
| Built-in barcodes | 1D, 2D, AZTECCODE, CODABAR (NW-7), Code 39, Code 93, Code-128 Codabar Library, Data Matrix, EAN13, EAN8, GS1 DataBar, ITF, MaxiCode, PDF417, QR Code, UPC-A, UPC-E |
| Features | |
| Magnetic stripe reader | Yes |
| Internal memory | 64 MB |
| Flash memory | 32 MB |
| Product colour | Black |
| Built-in barcodes | 1D, 2D, AZTECCODE, CODABAR (NW-7), Code 39, Code 93, Code-128 Codabar Library, Data Matrix, EAN13, EAN8, GS1 DataBar, ITF, MaxiCode, PDF417, QR Code, UPC-A, UPC-E |
| Design | |
| Product colour | Black |
| Memory | |
| Internal memory | 64 MB |
| Flash memory | 32 MB |
| Power | |
| AC input frequency | 50 - 60 Hz |
| Power consumption | 2600 mA |
| Power source type | AC, Battery |
| Battery voltage | 7.4 V |
| Battery technology | Lithium-Ion (Li-Ion) |
| Battery recharge time | 4 h |
| Operational conditions | |
| Storage temperature (T-T) | -30 - 70 °C |
| Operating temperature (T-T) | -15 - 50 °C |
| Operating relative humidity (H-H) | 10 - 80% |
| Weight & dimensions | |
| Width | 105 mm |
| Depth | 126 mm |
| Height | 58 mm |
| Weight | 385 g |
