Description
ADS-4100 Desktop document scanner, ADF, 35 ppm, 70 ipm, 600 x 600/1200 x 1200 dpi, 59 dB, USB
Simple and intuitive. This highly versatile scanner is ideal for businesses that need to digitise a wide range of media, from paper to plastic cards, whether at home or in the office.
Fast and reliable
With high-quality and robust roller mechanisms, the ADS-4100 has a large 60 sheet ADF capacity and can scan up to 35 pages per minute.
Simple and intuitive
Design simplicity means it's easy to set up and easy to use.
Advanced connectivity
With USB3.0 and USB host, you can securely scan documents without the need for a PC.
Advanced image capture and processing
Effortless and impressive image capture and processing - from easily referencing and locating scanned pages with the digital imprinter, to optimising image quality through the automatic vertical streaks and moiré reduction tools.
Brother ScanEssentials Lite
Our ScanEssentials Lite software enables you to scan documents easily, create simple workflows and save them securely to folders on your network, with minimum effort.
Industry recognised software
Increase post-scanning productivity with industry recognised software including Kofax and Newsoft, available as standard with device.
Key Features
- Scan up to 35 pages per minute
- 2-sided scan up to 35 pages per minute
- 60 sheet Automatic Document Feeder (ADF)
- SuperSpeed USB3.0
- Scan directly to USB host
- Brother ScanEssentials Lite software
- Advanced image processing
- Driver compatibility with TWAIN (Win and macOS), WIA, ICA, Linux SANE
Description
With simplicity built in. Robust, easy-to-use, every day scanner. Great for digitsing a range of media at home or in the office.Simple and intuitive. This highly versatile scanner is ideal for businesses that need to digitise a wide range of media, from paper to plastic cards, whether at home or in the office.
Fast and reliable
With high-quality and robust roller mechanisms, the ADS-4100 has a large 60 sheet ADF capacity and can scan up to 35 pages per minute.
Simple and intuitive
Design simplicity means it's easy to set up and easy to use.
Advanced connectivity
With USB3.0 and USB host, you can securely scan documents without the need for a PC.
Advanced image capture and processing
Effortless and impressive image capture and processing - from easily referencing and locating scanned pages with the digital imprinter, to optimising image quality through the automatic vertical streaks and moiré reduction tools.
Brother ScanEssentials Lite
Our ScanEssentials Lite software enables you to scan documents easily, create simple workflows and save them securely to folders on your network, with minimum effort.
Industry recognised software
Increase post-scanning productivity with industry recognised software including Kofax and Newsoft, available as standard with device.
Specifications
| Scanning | |
|---|---|
| Output greyscale depth | 8 bit |
| Maximum scan size | 215.9 x 355.6 mm |
| Optical scanning resolution | 600 x 600 DPI |
| Enhanced scan resolution | 1200 x 1200 DPI |
| Colour scanning | Yes |
| Duplex scanning | Yes |
| Input colour depth | 48 bit |
| Output colour depth | 24 bit |
| Greyscale levels | 256 |
| ADF scan speed (b/w, A4) | 35 ppm |
| ADF scan speed (colour, A4) | 35 ppm |
| Duplex ADF scan speed (b/w, A4) | 70 ipm |
| Duplex ADF scan speed (colour, A4) | 70 ipm |
| Sensor type | CIS |
| Light source | LED |
| Scan file formats | JPEG, PDF, TIFF |
| Daily duty cycle (max) | 5250 pages |
| Scan to | Image, PC, USB |
| Design | |
| Built-in display | No |
| Scanner type | ADF scanner |
| Product colour | Black, White |
| Control type | Buttons |
| Performance | |
| Sensor type | CIS |
| Light source | LED |
| Scan file formats | JPEG, PDF, TIFF |
| Daily duty cycle (max) | 5250 pages |
| Scan to | Image, PC, USB |
| Scan drivers | ICA, SANE, TWAIN, WIA |
| Scanning noise level | 59 dB |
| Maximum duty cycle | 105000 pages per month |
| Input capacity | |
| Auto document feeder (ADF) input capacity | 60 sheets |
| Paper handling | |
| Maximum scan width | 21.6 cm |
| Maximum scan length | 5 m |
| Maximum ISO A-series paper size | A4 |
| Media thickness (min) | 0.08 mm |
| Scanning media types supported | Business Card, Plain paper, Plastic Card, Recycled paper, Thick paper, Thin paper |
| Auto Document Feeder (ADF) media weight | 40 - 200 g/m² |
| Long-paper mode | Yes |
| Card thickness (max) | 1.1 mm |
| Paper tray media weight | 40 - 200 g/m² |
| Ports & interfaces | |
| USB port | Yes |
| USB version | 2.0/3.2 Gen 1 (3.1 Gen 1) |
| Software | |
| Windows operating systems supported | Yes |
| Mac operating systems supported | Yes |
| Linux operating systems supported | Yes |
| Server operating systems supported | Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019 |
| Scan drivers | ICA, SANE, TWAIN, WIA |
| Sound emission | |
| Scanning noise level | 59 dB |
| Power | |
| Power consumption (typical) | 23 W |
| Power consumption (standby) | 5.4 W |
| Power consumption (off) | 0.1 W |
| Power supply type | AC |
| Power consumption (sleep) | 1.4 W |
| Output voltage | 24 V |
| Output current | 1.9 A |
| AC input frequency | 50 - 60 Hz |
| Technical details | |
| Maximum scan width | 21.6 cm |
| Media thickness (min) | 0.08 mm |
| Scanner type | ADF scanner |
| Maximum duty cycle | 105000 pages per month |
| Product colour | Black, White |
| Harmonized System (HS) code | 84716070 |
| Compliance certificates | RoHS |
| Packaging data | |
| Package depth | 243 mm |
| Package weight | 3.31 kg |
| Package width | 391 mm |
| Package height | 320 mm |
| Quantity per pack | 1 pc(s) |
| Security | |
| Cable lock slot | Yes |
| System requirements | |
| Windows operating systems supported | Yes |
| Mac operating systems supported | Yes |
| Linux operating systems supported | Yes |
| Server operating systems supported | Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019 |
| Operational conditions | |
| Operating temperature (T-T) | 5 - 35 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 20 - 80% |
| Storage relative humidity (H-H) | 10 - 90% |
| Certificates | |
| Certification | GS Mark, WHQL |
| Weight & dimensions | |
| Package depth | 243 mm |
| Package weight | 3.31 kg |
| Width | 299.5 mm |
| Depth | 215.9 mm |
| Height | 190.5 mm |
| Weight | 2.6 kg |
| Package width | 391 mm |
| Package height | 320 mm |
| Packaging content | |
| Cables included | AC, USB |
| Other features | |
| Cable lock slot | Yes |
| Scanner type | ADF scanner |
| Quantity per pack | 1 pc(s) |
| Logistics data | |
| Quantity per pack | 1 pc(s) |
| Harmonized System (HS) code | 84716070 |
