With simplicity built in. Robust, easy-to-use, every day scanner. Great for digitsing a range of media at home or in the office.
Key Features
- Scan up to 35 pages per minute
- 2-sided scan up to 35 pages per minute
- 60 sheet Automatic Document Feeder (ADF)
- SuperSpeed USB3.
- Scan directly to USB host
- Brother ScanEssentials Lite software
Reasons To Buy
Simple and intuitive
Design simplicity means it's easy to set up and easy to use.
Advanced image capture and processing
Effortless and impressive image capture and processing - from easily referencing and locating scanned pages with the digital imprinter, to optimising image quality through the automatic vertical streaks and moiré reduction tools.
Advanced connectivity
With USB3.0 and USB host, you can securely scan documents without the need for a PC.
Brother ScanEssentials Lite
Our ScanEssentials Lite software enables you to scan documents easily, create simple workflows and save them securely to folders on your network, with minimum effort.
Fast and reliable
With high-quality and robust roller mechanisms, the ADS-4100 has a large 60 sheet ADF capacity and can scan up to 35 pages per minute.
Industry recognised software
Increase post-scanning productivity with industry recognised software including Kofax and Newsoft, available as standard with device.
Description
Simple and intuitive. This highly versatile scanner is ideal for businesses that need to digitise a wide range of media, from paper to plastic cards, whether at home or in the office. Advanced image processing Driver compatibility with TWAIN (Win and macOS), WIA, ICA, Linux SANE
Specifications
| Scanning |
|---|
| Maximum scan size |
215.9 x 355.6 mm |
| Optical scanning resolution |
600 x 600 DPI |
| Enhanced scan resolution |
1200 x 1200 DPI |
| Colour scanning |
Yes |
| Duplex scanning |
Yes |
| Greyscale levels |
256 |
| ADF scan speed (b/w, A4) |
35 ppm |
| ADF scan speed (colour, A4) |
35 ppm |
| Duplex ADF scan speed (b/w, A4) |
70 ipm |
| Duplex ADF scan speed (colour, A4) |
70 ipm |
| Sensor type |
Dual CIS |
| Scan to |
Image, PC, USB |
| Design |
|---|
| Built-in display |
No |
| Scanner type |
ADF scanner |
| Product colour |
Black, White |
| Control type |
Buttons |
| Performance |
|---|
| Sensor type |
Dual CIS |
| Scan to |
Image, PC, USB |
| Scan drivers |
ICA, SANE, WIA |
| Scanning noise level |
59 dB |
| Input capacity |
|---|
| Auto document feeder (ADF) input capacity |
60 sheets |
| Paper handling |
|---|
| Maximum scan width |
21.6 cm |
| Maximum scan length |
35.5 cm |
| Maximum ISO A-series paper size |
A4 |
| Scanning media types supported |
Business Card, Plain paper, Plastic Card, Recycled paper, Thick paper, Thin paper |
| Auto Document Feeder (ADF) media weight |
40 - 200 g/m² |
| Card thickness (max) |
1.1 mm |
| Ports & interfaces |
|---|
| USB port |
Yes |
| USB version |
2.0 |
| Software |
|---|
| Windows operating systems supported |
Yes |
| Mac operating systems supported |
Yes |
| Linux operating systems supported |
Yes |
| Server operating systems supported |
Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019 |
| Scan drivers |
ICA, SANE, WIA |
| Sound emission |
|---|
| Scanning noise level |
59 dB |
| Power |
|---|
| Power consumption (typical) |
23 W |
| Power consumption (standby) |
5.4 W |
| Power consumption (off) |
0.1 W |
| Power supply type |
AC |
| Power consumption (sleep) |
1.4 W |
| Weight & dimensions |
|---|
| Width |
243 mm |
| Depth |
320 mm |
| Height |
391 mm |
| Weight |
3.02 kg |
| Package depth |
320 mm |
| Package weight |
3.7 kg |
| Package width |
391 mm |
| Package height |
243 mm |
| Packaging data |
|---|
| Package depth |
320 mm |
| Package weight |
3.7 kg |
| Package width |
391 mm |
| Package height |
243 mm |
| Products per pallet |
50 pc(s) |
| Packaging content |
|---|
| Cables included |
AC, USB |
| Technical details |
|---|
| Maximum scan width |
21.6 cm |
| Pallet gross height |
17.7 cm |
| Scanner type |
ADF scanner |
| Country of origin |
China |
| Product colour |
Black, White |
| Layers per pallet |
5 pc(s) |
| Master (outer) cases per pallet |
50 pc(s) |
| Master (outer) cases per pallet layer |
10 pc(s) |
| Harmonized System (HS) code |
84716070 |
| Pallet type |
800 x 1200 mm |
| Features |
|---|
| Country of origin |
China |
| System requirements |
|---|
| Windows operating systems supported |
Yes |
| Mac operating systems supported |
Yes |
| Linux operating systems supported |
Yes |
| Server operating systems supported |
Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019 |
| Operational conditions |
|---|
| Operating temperature (T-T) |
5 - 35 °C |
| Operating relative humidity (H-H) |
20 - 80% |
| Other features |
|---|
| Spare part retention |
5 year(s) |
| Pallet gross weight |
202 kg |
| Scanner type |
ADF scanner |
| Country of origin |
China |
| Products per pallet |
50 pc(s) |
| Layers per pallet |
5 pc(s) |
| Master (outer) cases per pallet |
50 pc(s) |
| Logistics data |
|---|
| Pallet gross weight |
202 kg |
| Country of origin |
China |
| Products per pallet |
50 pc(s) |
| Layers per pallet |
5 pc(s) |
| Master (outer) cases per pallet |
50 pc(s) |
| Pallet gross height |
17.7 cm |
| Master (outer) cases per pallet layer |
10 pc(s) |
| Harmonized System (HS) code |
84716070 |
