USB-C Thunderbolt, 3 x USB 3.0, 2 x USB 2.0, 240W
Description
The Dell ThunderboltTM Dock TB16 -240W allows you to quickly connect your mobile workstation to a single data and power source for ultimate display performance and speedy data transfers. The dock connects to ThunderboltTM 3 enabled notebooks* with a single USB Type-C ThunderboltTM Cable, allowing users to quickly connect to multiple displays and peripherals, providing power to the notebook, and freeing up space on your desk and in your workspace
Specifications
| Ports & interfaces |
|---|
| Combo headphone/mic port |
Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
3 |
| Host interface |
Thunderbolt 3 |
| USB 2.0 ports quantity |
2 |
| Line-out |
Yes |
| Ethernet LAN (RJ-45) ports |
1 |
| HDMI ports quantity |
1 |
| VGA (D-Sub) ports quantity |
1 |
| DisplayPorts quantity |
1 |
| Mini DisplayPorts quantity |
1 |
| Microphone in |
No |
| DC-in jack |
Yes |
| Connectivity technology |
Wired |
| Network |
|---|
| Ethernet LAN |
Yes |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Ethernet LAN (RJ-45) ports |
1 |
| Performance |
|---|
| Number of displays supported |
3 |
| Product colour |
Black |
| Card reader integrated |
No |
| Cable lock slot |
Yes |
| LED indicators |
Yes |
| Cable lock slot type |
Kensington |
| Technical details |
|---|
| Product colour |
Black |
| Cable lock slot |
Yes |
| Harmonized System (HS) code |
84733020 |
| Storage |
|---|
| Card reader integrated |
No |
| Power |
|---|
| Power source type |
AC |
| AC input voltage |
120 - 230 V |
| AC input frequency |
50 - 60 Hz |
| Power supply |
240 W |
| Software |
|---|
| Windows operating systems supported |
Windows 10, Windows 7, Windows 8, Windows 8.1 |
| Linux operating systems supported |
Ubuntu 14.04 |
| Indication |
|---|
| LED indicators |
Yes |
| Weight & dimensions |
|---|
| Width |
145 mm |
| Depth |
145 mm |
| Height |
51 mm |
| Design |
|---|
| Windows operating systems supported |
Windows 10, Windows 7, Windows 8, Windows 8.1 |
| Product colour |
Black |
| Cable lock slot |
Yes |
| LED indicators |
Yes |
| Cable lock slot type |
Kensington |
| Packaging content |
|---|
| Cables included |
Thunderbolt |
| AC adapter included |
Yes |
| Logistics data |
|---|
| Harmonized System (HS) code |
84733020 |
