Description
254 mm (10") 1U fixed shelf 44x254x150 mm, color black (RAL 9005)
- Simple 2-point attachment to the 254 mm (10") profile rails via integrated mounting brackets with two screw holes each
- Slim design that only takes up 1 height unit
- Installation depth: 150 mm
- Load capacity of up to 25 kg
- Robust sheet steel construction with perforation for optimized air flow within the cabinet
The 10" shelves from DIGITUS® consist of a sturdy, perforated metal sheet and can be installed quickly and easily on the front 10" profiles. They are supplied complete with mounting material and are therefore ready for immediate use. Use the DIGITUS® 10" shelves to store components that are not mounted directly in your 10" enclosure.
Key Features
- Sturdy, perforated metal sheet
- Complete with mounting material
- Attachment to the front 10" rails
- Width x depth of storage surface inside: 210 x 147 mm
- Width x depth of the entire shelf outside: 254 x 149 mm
- 2-point attachment (front 10" profile rails)
Description
- Storage for accessories or components in the 254 (10") cabinet without own installation option- Simple 2-point attachment to the 254 mm (10") profile rails via integrated mounting brackets with two screw holes each
- Slim design that only takes up 1 height unit
- Installation depth: 150 mm
- Load capacity of up to 25 kg
- Robust sheet steel construction with perforation for optimized air flow within the cabinet
The 10" shelves from DIGITUS® consist of a sturdy, perforated metal sheet and can be installed quickly and easily on the front 10" profiles. They are supplied complete with mounting material and are therefore ready for immediate use. Use the DIGITUS® 10" shelves to store components that are not mounted directly in your 10" enclosure.
Specifications
| Features | |
|---|---|
| Type | Rack shelf |
| Size (imperial) | 25.4 cm (10") |
| Rack capacity | 1U |
| Maximum weight capacity | 25 kg |
| Product colour | Black |
| Harmonized System (HS) code | 85389099 |
| Housing material | Steel |
| Country of origin | Turkey |
| Weight & dimensions | |
| Package volume | 2227.5 cm³ |
| Package width | 270 mm |
| Package depth | 165 mm |
| Package weight | 450 g |
| Useful width | 15 cm |
| Width | 254 mm |
| Size (imperial) | 25.4 cm (10") |
| Depth | 44 mm |
| Maximum weight capacity | 25 kg |
| Packaging data | |
| Package volume | 2227.5 cm³ |
| Package width | 270 mm |
| Package depth | 165 mm |
| Package weight | 450 g |
| Technical details | |
| Type | Rack shelf |
| Size (imperial) | 25.4 cm (10") |
| Rack capacity | 1U |
| Colour | |
| Product colour | Black |
| Logistics data | |
| Harmonized System (HS) code | 85389099 |
| UK Trade Tariff code | 94039910 |
