Description
4K Wireless HDMI Extender/Splitter Set, 1x4 150 m, 1x TX, 1x RX
- Wireless HDMI signal transmission up to 150 m (unrestricted view)
- Point-to-multipoint connection - 1x transmitter (source) + up to 4x receivers (output device)
- Additional receiver units available separately: DS-55329
- Supports wireless AV signal transmission with resolutions up to 4K UHD (2160p/30Hz)
- Simple operation and handling thanks to Plug & Play - plug in and go, no drivers or software required
- Automatic pairing & connection: Automatically establishes a connection via the most advantageous WiFi channel to ensure the best possible WiFi performance
- KVM functionality for connecting mouse & keyboard
- Touch Screen Back Control - Supports touch screen panels (via USB connection on the receiver)
- Power supply via USB-C connection + power supply unit (included)
- AES 128 bit encryption / WPA2 protocol
- HDMI 2.0 / HDCP 2.2
The 4K Wireless HDMI KVM Extender Set transmits your HDMI video and audio signals in UHD 4K/30Hz resolution wirelessly over a distance of up to 150 m (unrestricted view). This consists of a transmitter and receiver unit. Thanks to KVM functionality, a mouse/keyboard can be connected to the receiver unit, allowing the signal source to be controlled directly on the output device. A local monitor can be connected via the HDMI loop-out on the transmitter unit to control the output on the receiver. The extender set can be expanded to up to 4 receivers (output devices) - additional receivers available separately: DS-55329.
Key Features
- Wireless HDMI signal transmission up to 150 m (unrestricted view)
- Point-to-multipoint connection - 1x transmitter (source) + up to 4x receivers (output device)
- Additional receiver units available separately: DS-55329
- Supports wireless AV signal transmission with resolutions up to 4K UHD (2160p/30Hz)
- Simple operation and handling thanks to Plug & Play - plug in and go, no drivers or software required
- Touch Screen Back Control - Supports touch panels (via USB connection on the receiver)
- Authentication protocol: WPA2 (WPAS-PSK / WPA2-Enterprise), AES 128 bit encryption
- Transmission distance 1:1 connection: up to 150 m (unrestricted view)
- Transmission distance 1:2 connection: up to 100 m (unrestricted view)
- Transmission distance 1:3 connection: up to 30 m (unrestricted view)
- Transmission distance 1:4 connection: up to 15 m (unrestricted view)
- HDMI version: 2.0
- HDCP version: 2.2
- Radio channel: IEEE 802.11.b/g/n/ac
- Frequency band: Dual band, 2.4/5G
- Compression: H.265
- Latency: approx. 100 ms (transmitter to receiver transmission)
- Audio format: PCM
- Audio channel: 2 channels
- Transmitter unit connections:
- 1x HDMI input (signal source, 4K/60Hz max.)
- 1x HDMI loop-out / output (output device, 4K/60Hz max.)
- 1x micro USB input - data connection of the source for using the KVM function
- 1x IR output - Connection of IR transmitter to control the signal source
- 1x USB-C input - power supply connection (5V/2A)
- 1x On/Off switch
- Receiver unit connections:
- 1x HDMI output (output device, 4K/60Hz max.)
- 2x USB-A input (connection of mouse/keyboard/touch panel)
- 1x Reset button
- Housing: Metal
- Color: black
- Dimensions (1 unit): W 15.4 x D 7.75 x H 2.1 cm
- Weight (1 unit): 330 g
- Power consumption (1 unit): approx. 5W
- Operating temperature: 0-40°C
- The transmission distance with limited visibility cannot be determined across the board and depends on the conditions on site
- Walls, glass, etc. shorten the signal coverage or cause signal loss
Description
Transmits HDMI video and audio signals wirelessly in UHD 4K/30Hz over a distance of up to 150 m in clear view and offers KVM functionality- Wireless HDMI signal transmission up to 150 m (unrestricted view)
- Point-to-multipoint connection - 1x transmitter (source) + up to 4x receivers (output device)
- Additional receiver units available separately: DS-55329
- Supports wireless AV signal transmission with resolutions up to 4K UHD (2160p/30Hz)
- Simple operation and handling thanks to Plug & Play - plug in and go, no drivers or software required
- Automatic pairing & connection: Automatically establishes a connection via the most advantageous WiFi channel to ensure the best possible WiFi performance
- KVM functionality for connecting mouse & keyboard
- Touch Screen Back Control - Supports touch screen panels (via USB connection on the receiver)
- Power supply via USB-C connection + power supply unit (included)
- AES 128 bit encryption / WPA2 protocol
- HDMI 2.0 / HDCP 2.2
The 4K Wireless HDMI KVM Extender Set transmits your HDMI video and audio signals in UHD 4K/30Hz resolution wirelessly over a distance of up to 150 m (unrestricted view). This consists of a transmitter and receiver unit. Thanks to KVM functionality, a mouse/keyboard can be connected to the receiver unit, allowing the signal source to be controlled directly on the output device. A local monitor can be connected via the HDMI loop-out on the transmitter unit to control the output on the receiver. The extender set can be expanded to up to 4 receivers (output devices) - additional receivers available separately: DS-55329.
Specifications
| Features | |
|---|---|
| Material | Metal |
| HDCP | Yes |
| Audio output channels | 2.0 channels |
| Plug and Play | Yes |
| Maximum refresh rate | 30 Hz |
| On/off switch | Yes |
| Video compression formats | H.265 |
| Security algorithms | WPA2, 128-bit AES |
| Audio formats supported | PCM |
| Type | AV transmitter & receiver |
| Maximum resolution | 3840 x 2160 pixels |
| Maximum transfer distance | 150 m |
| Supported video modes | 1080p, 2160p |
| Supported graphics resolutions | 3840 x 2160, 1920 x 1080 (HD 1080) |
| LED indicators | Status |
| Product colour | Black |
| HDCP version | 2.2 |
| Technical details | |
| Material | Metal |
| HDCP | Yes |
| Audio output channels | 2.0 channels |
| Plug and Play | Yes |
| Maximum refresh rate | 30 Hz |
| On/off switch | Yes |
| Wi-Fi | Yes |
| Video compression formats | H.265 |
| Security algorithms | WPA2, 128-bit AES |
| Audio formats supported | PCM |
| Type | AV transmitter & receiver |
| Maximum resolution | 3840 x 2160 pixels |
| Maximum transfer distance | 150 m |
| Supported video modes | 1080p, 2160p |
| Supported graphics resolutions | 3840 x 2160, 1920 x 1080 (HD 1080) |
| Product colour | Black |
| Connectivity technology | Wired & Wireless |
| Quantity per pack | 2 pc(s) |
| Ports & interfaces | |
| Remote (IR) output | 1 |
| USB ports quantity | 5 |
| Wi-Fi | Yes |
| USB connector type | Micro-USB A, USB Type-A, USB Type-C |
| HDMI in | 1 |
| Number of HDMI outputs | 2 |
| HDMI version | 2.0 |
| Connectivity technology | Wired & Wireless |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| Power | |
| Power consumption (typical) | 5 W |
| Indication | |
| LED indicators | Status |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Weight & dimensions | |
| Width | 154 mm |
| Package depth | 233 mm |
| Height | 21 mm |
| Depth | 77.5 mm |
| Package width | 250 mm |
| Package height | 57 mm |
| Weight | 330 g |
| Package weight | 1.16 kg |
| Packaging data | |
| Package depth | 233 mm |
| Package width | 250 mm |
| Package height | 57 mm |
| Package weight | 1.16 kg |
| Quantity per pack | 2 pc(s) |
| Packaging content | |
| Cables included | HDMI, IR, USB |
| Quick start guide | Yes |
| AC adapter included | Yes |
