Description
Desktop HDMI KVM Switch
- Use one monitor, a mouse and keyboard to operate 4 computers with single display
- Supports a maximum UHD resolution of 4K / 30 Hz + FreeSync
- USB ports for mouse and keyboard
- Audio connections for microphone/speaker, supports Dolby True HD and DTS HD Master Audio
- Integrated USB hub with USB A port for additional peripheral equipment
- Switching between the PCs via switch on the KVM switch or hot key on the keyboard
- LED status and functional displays on the front side
- Laborious replugging of connection cables no longer necessary
- Real Plug and Play - no software or driver installation required (BIOS hardware connection)
- Sturdy metal housing
With the DIGITUS® 4 Port KVM Switch for single displays, you can operate four 4K-compatible PCs using a single USB keyboard and mouse combination. By pressing a button or hot key, you can switch comfortably between the two PCs and are spared the trouble of replugging all cables. Output to one monitor is provided via the HDMI® output on the rear side. You can also switch between the audio signals for the microphone and speaker. In addition, a USB port is included on the front side for use with other peripheral devices like USB sticks or external hard drives on both PCs. The connected peripheral devices are each assigned to the active PC. Status LEDs on the front side of the switch show you the current configuration at all times. The switch features the added benefits of sturdy metal housing.
Key Features
- UHD resolution: 4K / 30 Hz (3840 x 2160p) / subsampling: YUV 4:4:4
- Inputs: 4 x HDMI® inputs (4x1), 4 x USB B, 4 x audio combo socket 3.5 mm jack (microphone, loudspeaker)
- Outputs (console): 1 x HDMI®, 2 x USB A (mouse, keyboard), 2 x stereo audio 3.5 mm jack (microphone, speakers)
- Additional connection on the front: 1 x USB A for additional peripheral devices such as printers or USB sticks
- HDMI® version: 1.4b
- USB specification: USB 2.0 compliant (FullSpeed)
- Supported audio formats: Dolby True HD, DTS HD Master Audio
- Switching between the PCs: Switch on the front panel or hot keys
- Status LED on front panel shows current configuration
- The device is platform-independent and suitable for all operating systems.
- Operating temperature: 0°C ~ 50°C
- Storage temperature: -20°C ~ 60°C
- Operating humidity: 0 - 80% RH (non-condensing)
- Housing material: metal
- Power supply: via USB or optional 9 V DC power supply unit
- Dimensions: 20.2 x 11 x 4.4 cm (WxDxH)
- Weight: 780 g
- Color: Black
- Power supply: AC 100-240V
- Power consumption: 2.7W
- DC-STE connector size: 5.5*2.1mm
Description
Operate 4 PCs using an USB keyboard and mouse combination – switch between two computers by pressing a button- Use one monitor, a mouse and keyboard to operate 4 computers with single display
- Supports a maximum UHD resolution of 4K / 30 Hz + FreeSync
- USB ports for mouse and keyboard
- Audio connections for microphone/speaker, supports Dolby True HD and DTS HD Master Audio
- Integrated USB hub with USB A port for additional peripheral equipment
- Switching between the PCs via switch on the KVM switch or hot key on the keyboard
- LED status and functional displays on the front side
- Laborious replugging of connection cables no longer necessary
- Real Plug and Play - no software or driver installation required (BIOS hardware connection)
- Sturdy metal housing
With the DIGITUS® 4 Port KVM Switch for single displays, you can operate four 4K-compatible PCs using a single USB keyboard and mouse combination. By pressing a button or hot key, you can switch comfortably between the two PCs and are spared the trouble of replugging all cables. Output to one monitor is provided via the HDMI® output on the rear side. You can also switch between the audio signals for the microphone and speaker. In addition, a USB port is included on the front side for use with other peripheral devices like USB sticks or external hard drives on both PCs. The connected peripheral devices are each assigned to the active PC. Status LEDs on the front side of the switch show you the current configuration at all times. The switch features the added benefits of sturdy metal housing.
Specifications
| Ports & interfaces | |
|---|---|
| Console ports | HDMI, USB A |
| USB connector type | USB Type-A, USB Type-B |
| HDMI version | 1.4b |
| Number of computers controlled | 4 |
| Keyboard port type | USB |
| Mouse port type | USB |
| Video port type | HDMI/DisplayPort |
| Audio connections | Yes |
| HDMI ports quantity | 5 |
| USB 2.0 Type-B ports quantity | 4 |
| USB 2.0 Type-A hub ports quantity | 2 |
| Performance | |
| HD type | 4K Ultra HD |
| Video bandwidth | 30 Hz |
| Plug and Play | Yes |
| Maximum resolution | 3840 x 2160 pixels |
| Technical details | |
| Product colour | Black |
| Rack mounting | No |
| Plug and Play | Yes |
| LED indicators | Status |
| Design | |
| Product colour | Black |
| Rack mounting | No |
| LED indicators | Status |
| Housing material | Metal |
| Country of origin | China |
| Display | |
| Built-in display | No |
| Video | |
| HD type | 4K Ultra HD |
| Video bandwidth | 30 Hz |
| Maximum resolution | 3840 x 2160 pixels |
| Features | |
| Country of origin | China |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 80% |
| Weight & dimensions | |
| Width | 202 mm |
| Depth | 110 mm |
| Height | 44 mm |
| Weight | 780 g |
| Packaging content | |
| Cables included | KVM |
| Quick installation guide | Yes |
| Logistics data | |
| Country of origin | China |
| Harmonized System (HS) code | 85176200 |
