Digitus Slide rails for 482.6 mm (19") network enclosures

Slide rails, L shape, for 600-800 mm depth racks adjustable 350-600 mm depth, set with 2 pieces

Key Features

• for fixed installation on the four 482.6 mm (19") profile rails
• Galvanized sheet steel with a thickness of 2.00 mm
• Load capacity: 100 kg
• 1 piece consists of two parts (internal and external profile system)
• 1 set = 2 pieces
• Variable depth: 350 mm to 600 mm
• incl. mounting material

Description

For supporting heavy built-in components, such as UPS systems or servers. Infinitely variable depth and suitable for 19" installation.

- Easy installation in the 19" level without cage nuts thanks to threaded holes.
- For DIGITUS® network cabinets Unique, Unique Light with 600 mm or 800 mm external depth.
- Infinitely variable depth: 350 mm to 600 mm
- Load capacity: 100 kg

The slide rails are used to support heavy installations in DIGITUS® network enclosures of the Unique & Unique Light series. They are attached to the front and rear 482.6 mm 19" profile rails. Made of galvanized sheet steel and loadable up to 100 kg. The rails are infinitely variable in depth to adapt to individual spacing in the 19" plane.

Specifications

Technical details
Country of origin	Turkey
Maximum weight capacity	100 kg
Material	Steel
Product colour	Stainless steel
Weight & dimensions
Weight	2.65 kg
Width	52 mm
Depth	600 mm
Height	44 mm
Size (imperial)	48.3 cm (19")
Packaging data
Package width	65 mm
Package height	65 mm
Package depth	370 mm
Package weight	3.2 kg
