Description
USB4 Gen2 connection cable,TypeC to TypeC,Al-Hous. PP Braid 8K@30Hz,4K@60Hz,PD3.0,20Gbits/s,3m, bl.
- Supports data transfer rates of up to 20 Gbit/s
- Supports USB Power Delivery Revision 3.0 (PD 3.0) with 20V, 3A and 60W
- Backwards compatible with Thunderbolt 3, USB 3.2, USB 3.1 and USB 2.0
- Supports DisplayPort (2.0) video/audio signals and PCi Express
- Video/audio support up to 8K (7680 × 4320 pixels at 30Hz)
The Digitus® 3rd generation USB 4.0 cable with aluminum housing is the all-rounder among cables. Thanks to the Thunderbolt 3 protocol, PCI Express, DisplayPort and host-to-host transmissions can be realized. You can use this cable to transfer audio/video signals, data and power. The data transfer speed is 20 Gbit/s, which is 4x faster than USB 3.0 (5 Gbit/s) and 2x faster than USB 3.1 (10 Gbit/s). This allows you to transfer large data such as movies and music within seconds. The video signals are transmitted in max. 8K at a refresh rate of 30 Hz. In addition, the resolutions 8K (7680 × 4320) @30Hz. (dual mode possible) and 4K (3840 x 2160) @60Hz are also supported. Thanks to USB Power Delivery Revision 3.0, the fast charging function is guaranteed. With the corresponding charger, you can charge your smart devices with max. 60 W (3 A / 20 V) in a short time. The USB Type-C interface enables broad compatibility with devices with this connection.
Key Features
- Supports: 8K (7680 × 4320) @30Hz.
- Supports: 4K (3840 x 2160) @60Hz
- Supports data transfer rates of up to 20 Gbit/s
- Backwards compatible with Thunderbolt 3, USB 3.2, USB 3.1 and USB 2.0
- Supports USB Power Delivery Revision 3.0 (PD 3.0) with 20V, 3A and 60W
- Core material: CU
- Connection 1: USB type C, plug
- Connection 2: USB type C, plug
- Dimension plug 1 : 6.65*2.4mm
- Dimension plug 2 : 6.65*2.4mm
- Color connections: Black
- Contact surface: gold-plated
- Number of PINS: 22
- Hood: potted
- Cable outer material: PP
- Plug housing: Aluminum
- Cable outer diameter: 5.0 mm
- Tensile strength: 4 kg/min
- AWG: 30
- Bending radius: 60
- Cable color: Black
- Shielding: Double shielded
- USB-C product: yes
- Total weight: 45g
- Manufacturer's instructions:
- If you connect a USB-C monitor/TV/projector to a PC equipped with USB Type-C, please make sure that your USB-C display supports DisplayPort signal output.
- The video output capability depends on the graphics card of your notebook and the connected monitor. Some monitors also limit the available resolution.
- To use a dual 4K output, the USB 4 device must support the PD3.0 protocol
Description
The USB 4.0 cable is an all-rounder and supports the following transmission types: audio/video/data transfer/charging function- Supports data transfer rates of up to 20 Gbit/s
- Supports USB Power Delivery Revision 3.0 (PD 3.0) with 20V, 3A and 60W
- Backwards compatible with Thunderbolt 3, USB 3.2, USB 3.1 and USB 2.0
- Supports DisplayPort (2.0) video/audio signals and PCi Express
- Video/audio support up to 8K (7680 × 4320 pixels at 30Hz)
The Digitus® 3rd generation USB 4.0 cable with aluminum housing is the all-rounder among cables. Thanks to the Thunderbolt 3 protocol, PCI Express, DisplayPort and host-to-host transmissions can be realized. You can use this cable to transfer audio/video signals, data and power. The data transfer speed is 20 Gbit/s, which is 4x faster than USB 3.0 (5 Gbit/s) and 2x faster than USB 3.1 (10 Gbit/s). This allows you to transfer large data such as movies and music within seconds. The video signals are transmitted in max. 8K at a refresh rate of 30 Hz. In addition, the resolutions 8K (7680 × 4320) @30Hz. (dual mode possible) and 4K (3840 x 2160) @60Hz are also supported. Thanks to USB Power Delivery Revision 3.0, the fast charging function is guaranteed. With the corresponding charger, you can charge your smart devices with max. 60 W (3 A / 20 V) in a short time. The USB Type-C interface enables broad compatibility with devices with this connection.
Specifications
| Features | |
|---|---|
| Country of origin | China |
| Connector 1 form factor | Straight |
| Connector 2 form factor | Straight |
| Ferrite bead | No |
| Plug and Play | Yes |
| AWG wire size | 30 |
| USB version | USB4 Gen 2x2 |
| Connector 1 | USB C |
| Connector 2 | USB C |
| Cable length | 3 m |
| Connector contacts plating | Gold |
| Magnetically shielded | Yes |
| Maximum data transfer rate | 20000 Mbit/s |
| Product colour | Black |
| Cable type | Round cable |
| Connector 1 gender | Male |
| Connector 2 gender | Male |
| USB Power Delivery (USB PD) | Yes |
| Cable jacket material | Polypropylene |
| USB Power Delivery up to | 100 W |
| USB Power Delivery revision | 3.0 |
| Connector material | Aluminium |
| Cable jacket type | Extremely flexible |
| Maximum resolution | 7680 x 4320 pixels |
| Maximum refresh rate | 60 Hz |
| Maximum data transfer rate | 20 Gbit/s |
| Cable diameter | 5 mm |
| Quantity per pack | 1 pc(s) |
| Weight & dimensions | |
| Cable diameter | 5 mm |
| Cable length | 3 m |
| Bend radius (min) | 6 cm |
| Package width | 230 mm |
| Package depth | 80 mm |
| Package height | 40 mm |
| Package weight | 200.6 g |
| Packaging data | |
| Package volume | 736 cm³ |
| Package width | 230 mm |
| Package depth | 80 mm |
| Package height | 40 mm |
| Package weight | 200.6 g |
| Quantity per pack | 1 pc(s) |
| Packaging content | |
| Quantity per pack | 1 pc(s) |
| Ports & interfaces | |
| USB version | USB4 Gen 2x2 |
| Connector 1 | USB C |
| Connector 2 | USB C |
| Connector contacts plating | Gold |
| Data transmission | |
| Maximum data transfer rate | 20000 Mbit/s |
| Technical details | |
| Magnetically shielded | Yes |
| Product colour | Black |
| Country of origin | China |
| Ferrite bead | No |
| Other features | |
| Product colour | Black |
| Cable type | Round cable |
| Logistics data | |
| Country of origin | China |
| Package volume | 736 cm³ |
| UK Trade Tariff code | 85444290 |
