Description
USB Type C 2.0 to serial Converter, DSUB 9M 1m cable length, FTDI chipset
- Enables the transfer of data between a PC and serial devices (machine controls, modems, sensors, and so on)
- Conforms to the USB 2.0 standard
The DIGITUS® USB Type-C™ serial adapter is a practical solution for serial connectivity. RS232 serial interfaces are no longer available on new hardware, so the DIGITUS® USB Type-C™ serial adapter enables data exchange between a computer USB Type-C™ port and peripheral devices with serial interfaces (COM port, RS232). These include, for example, weather stations, sensors, machine control systems, set-top boxes, gaming consoles, PDAs, scanners, modems, ISDN adapters and many other peripheral devices. The USB Type-C™ serial adapter is downwardly compatible with USB 1.1 and enables adaptable baud rates of between 75 and 128,000 bits per second. The customizable FTDI chipset is compatible with all common operating systems and also supports power management and remote wake up. A separate power supply is not required, because the device is powered through the USB connection.
Key Features
- Provides a serial RS232 interface via USB Type-C™
- Compliant with USB 2.0 standards
- Downward compatibility with USB 1.1
- Data transfer rates 1Mbps and more
- Support remote wake-up and power management
- Cable length: 1m
- Chipset: FTDI / FT232RL
- Supports Windows 11, 10, 8.1, 8, 7, Vista, XP, Mac OS X and Linux
Description
Connects serial devices via USB Type-C™ port to a PC- Enables the transfer of data between a PC and serial devices (machine controls, modems, sensors, and so on)
- Conforms to the USB 2.0 standard
The DIGITUS® USB Type-C™ serial adapter is a practical solution for serial connectivity. RS232 serial interfaces are no longer available on new hardware, so the DIGITUS® USB Type-C™ serial adapter enables data exchange between a computer USB Type-C™ port and peripheral devices with serial interfaces (COM port, RS232). These include, for example, weather stations, sensors, machine control systems, set-top boxes, gaming consoles, PDAs, scanners, modems, ISDN adapters and many other peripheral devices. The USB Type-C™ serial adapter is downwardly compatible with USB 1.1 and enables adaptable baud rates of between 75 and 128,000 bits per second. The customizable FTDI chipset is compatible with all common operating systems and also supports power management and remote wake up. A separate power supply is not required, because the device is powered through the USB connection.
Specifications
| Technical details | |
|---|---|
| Connector 1 | DB-9 |
| Product colour | Black |
| Cable length | 1 m |
| Package width | 86 mm |
| Features | |
| Connector 1 | DB-9 |
| Product colour | Black |
| Cable length | 1 m |
| Country of origin | China |
| Connector 2 gender | Male |
| Connector 1 gender | Male |
| Packaging data | |
| Package weight | 112 g |
| Package depth | 203 mm |
| Package volume | 401.534 cm³ |
| Package width | 86 mm |
| Logistics data | |
| Harmonized System (HS) code | 84733080 |
| UK Trade Tariff code | 84718000 |
