508 dpi, Micro USB, 5V DC, 119.6x43.7x25.3 mm
Description
Elo’s Fingerprint Scanner delivers a fast and reliable way to use biometric authentication for individuals who require access to a device or building. From patient and doctor authentication to employee login, the reader seamlessly integrates with a variety of Elo displays via Elo Edge Connect technology. By using a capacitive sensor for scanning, the Fingerprint Scanner can withstand up to four million touches - providing the durability you need with high quality scans time after time.
Specifications
| Technical details |
|---|
| Maximum scan resolution |
508 x 508 DPI |
| Interface |
Micro-USB |
| Scan area |
12.8 x 18 mm |
| Greyscale levels |
8 |
| Weight & dimensions |
|---|
| Width |
119.6 mm |
| Depth |
43.7 mm |
| Height |
25.3 mm |
| Weight |
4 g |
| Package weight |
150 g |
| Package width |
114 mm |
| Package height |
69 mm |
| Package depth |
175 mm |
| Power |
|---|
| USB powered |
Yes |
| Colour |
|---|
| Product colour |
Black |
| Operational conditions |
|---|
| Operating temperature (T-T) |
10 - 40 °C |
| Storage temperature (T-T) |
0 - 50 °C |
| Operating relative humidity (H-H) |
20 - 80% |
| Storage relative humidity (H-H) |
10 - 90% |
| Packaging data |
|---|
| Package weight |
150 g |
