Description
ES-C320W
A4 compact scanner with Wi-Fi and an incredibly small footprint while in use, versatile media handling and low power consumption.
The scanner's U-turn path position allows paper to be scanned without adding to the footprint of the device. Switch to straight path mode to scan passports and booklets up to 5mm thick. Paper protection technology ensures that the original documents remain pristine. Made from up to 30% recycled plastics* and with a low power consumption, it also has a lower environmental impact.
Description
Compact Wi-Fi scannerA4 compact scanner with Wi-Fi and an incredibly small footprint while in use, versatile media handling and low power consumption.
The scanner's U-turn path position allows paper to be scanned without adding to the footprint of the device. Switch to straight path mode to scan passports and booklets up to 5mm thick. Paper protection technology ensures that the original documents remain pristine. Made from up to 30% recycled plastics* and with a low power consumption, it also has a lower environmental impact.
Specifications
| Scanning | |
|---|---|
| Output monochrome depth | 8 bit |
| Maximum scan size | 215.9 x 3048 mm |
| Optical scanning resolution | 600 x 600 DPI |
| Duplex scanning | Yes |
| Input colour depth | 30 bit |
| Output colour depth | 24 bit |
| Light source | ReadyScan LED |
| Daily duty cycle (max) | 3500 pages |
| Scan to | E-mail, FTP, Network folder, Print |
| Design | |
| Built-in display | No |
| Scanner type | ADF + Sheet-fed scanner |
| Product colour | Black |
| Control type | Buttons |
| Performance | |
| Light source | ReadyScan LED |
| Daily duty cycle (max) | 3500 pages |
| Scan to | E-mail, FTP, Network folder, Print |
| Scan drivers | ISIS, SANE, WIA |
| Input capacity | |
| Standard input capacity | 20 sheets |
| Paper handling | |
| Maximum ISO A-series paper size | A4 |
| Scanning media types supported | Business Card, Plastic Card, Post Card(JPN) |
| Letter | Yes |
| Legal | Yes |
| ISO B-series sizes (B0...B9) | B5 |
| ISO A-series sizes (A0...A9) | A4, A5, A6 |
| Paper tray media weight | 40 - 413 g/m² |
| Ports & interfaces | |
| USB port | Yes |
| USB version | 2.0 |
| Software | |
| Windows operating systems supported | Windows 10, Windows 11, Windows 7, Windows 8 |
| Server operating systems supported | Windows Server 2003, Windows Server 2008, Windows Server 2008 R2, Windows Server 2012 R2, Windows Server 2012 x64, Windows Server 2016 |
| Scan drivers | ISIS, SANE, WIA |
| Power | |
| Power consumption (typical) | 10 W |
| Power consumption (standby) | 1 W |
| Input voltage | 100 - 240 V |
| Power supply type | AC |
| Power consumption (PowerSave) | 3.3 W |
| Media formats | |
| Letter | Yes |
| Legal | Yes |
| ISO B-series sizes (B0...B9) | B5 |
| ISO A-series sizes (A0...A9) | A4, A5, A6 |
| Network | |
| Wi-Fi | Yes |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| Technical details | |
| Scanner type | ADF + Sheet-fed scanner |
| Product colour | Black |
| System requirements | |
| Windows operating systems supported | Windows 10, Windows 11, Windows 7, Windows 8 |
| Server operating systems supported | Windows Server 2003, Windows Server 2008, Windows Server 2008 R2, Windows Server 2012 R2, Windows Server 2012 x64, Windows Server 2016 |
| Operational conditions | |
| Operating temperature (T-T) | 5 - 35 °C |
| Storage temperature (T-T) | -25 - 60 °C |
| Operating relative humidity (H-H) | 15 - 80% |
| Storage relative humidity (H-H) | 15 - 85% |
| Weight & dimensions | |
| Width | 296 mm |
| Depth | 104 mm |
| Height | 125 mm |
| Weight | 1.8 kg |
| Other features | |
| Wi-Fi | Yes |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| Scanner type | ADF + Sheet-fed scanner |
