Description
350 / 200 mm/sec, 180 x 180 DPI, USB, Ethernet, NFC, 127 x 127 x 127 mm, EU, Black
Print receipts anywhere on the shop floor thanks to this printer's easy connectivity with any smart device and its compact and flexible design.
With a focus on mobile connectivity and a small footprint, this compact receipt printer is ideal for tablet POS environments, such as hospitality and specialist retail outlets. Its design makes it ideal for customers looking to move to a tablet POS system, including those currently using PC POS. And, as one of the smallest stationary POS printers in the world, it’s easy to position anywhere.
Built for easy connectivity with tablets
By touching an NFC-equipped mobile device or tablet to the TM-m30 printer, it is easy to pair both together to print. ePOS print, the printer's built-in intelligence that communicates with web applications, allows direct printing from ANY mobile device without the need to install or update drivers. It is available for iOS, Android and Windows.
Position anywhere thanks to its sleek, compact and stylish design
With its sleek, stylish and compact design, the new TM-m50 is ideal for tablet POS applications and fits perfectly into small and medium-sized retail and hospitality environments, helping them to operate more efficiently and productively. With Ethernet, Bluetooth or Wi-Fi interfaces, it can be integrated into virtually any operating environment. By easily swapping just two covers the printer can be placed either horizontally or vertically - therefore top load or front load is possible.
High quality and adaptable
The new DM-D30 optional display is developed to match the modern design of the TM-m50 printer and an optional tablet stand is also available. Available in both black and white, this printer can print receipts in multiple greyscales, with advanced graphic and barcode printing capabilities that allow for highly customised layouts of receipts, including logos and promotional messages, that can be added with ease.
Key Features
- Designed for tablet POS: A focus on mobile connectivity and a small footprint
- NFC connectivity: Easily print by touching an NFC-equipped mobile device or tablet
- Support for wired barcode scanners: Firmware update enhances TM-m50 functionality
- ePOS print: Direct printing from ANY mobile device
- Optional customer display: & optional tablet stand available
Description
Gateway to tablet POSPrint receipts anywhere on the shop floor thanks to this printer's easy connectivity with any smart device and its compact and flexible design.
With a focus on mobile connectivity and a small footprint, this compact receipt printer is ideal for tablet POS environments, such as hospitality and specialist retail outlets. Its design makes it ideal for customers looking to move to a tablet POS system, including those currently using PC POS. And, as one of the smallest stationary POS printers in the world, it’s easy to position anywhere.
Built for easy connectivity with tablets
By touching an NFC-equipped mobile device or tablet to the TM-m30 printer, it is easy to pair both together to print. ePOS print, the printer's built-in intelligence that communicates with web applications, allows direct printing from ANY mobile device without the need to install or update drivers. It is available for iOS, Android and Windows.
Position anywhere thanks to its sleek, compact and stylish design
With its sleek, stylish and compact design, the new TM-m50 is ideal for tablet POS applications and fits perfectly into small and medium-sized retail and hospitality environments, helping them to operate more efficiently and productively. With Ethernet, Bluetooth or Wi-Fi interfaces, it can be integrated into virtually any operating environment. By easily swapping just two covers the printer can be placed either horizontally or vertically - therefore top load or front load is possible.
High quality and adaptable
The new DM-D30 optional display is developed to match the modern design of the TM-m50 printer and an optional tablet stand is also available. Available in both black and white, this printer can print receipts in multiple greyscales, with advanced graphic and barcode printing capabilities that allow for highly customised layouts of receipts, including logos and promotional messages, that can be added with ease.
Specifications
| Printing | |
|---|---|
| Character sets | ANK |
| Type | POS printer |
| Print technology | Direct thermal |
| Print speed | 350 mm/sec |
| Maximum resolution | 180 x 180 DPI |
| Print speed (receipt) | 350 mm/sec |
| Printing characters | Text, Graphic, Barcode |
| Performance | |
| Character sets | ANK |
| Type | POS printer |
| Print technology | Direct thermal |
| Print speed | 350 mm/sec |
| Maximum resolution | 180 x 180 DPI |
| Paper handling | |
| Supported paper width | 58 mm - 80 mm (Breite) |
| Maximum roll diameter | 8.3 cm |
| Ports & interfaces | |
| Connectivity technology | Wired |
| USB 2.0 ports quantity | 2 |
| USB port | Yes |
| USB connector | USB Type-A / USB Type-B |
| Serial interface | Yes |
| Serial interface type | RS-232C |
| Near Field Communication (NFC) | Yes |
| Network | |
| Ethernet LAN | Yes |
| Wi-Fi | No |
| Print technology | |
| Type | POS printer |
| Print technology | Direct thermal |
| Print speed | 350 mm/sec |
| Column capacity | 48/57 |
| Print quality | |
| Maximum resolution | 180 x 180 DPI |
| Technical details | |
| Mean cycles between failures (MCBF) | 70000000 |
| Character sets | ANK |
| Built-in sensors details | Paper End Sensor, Papier-Sensor |
| Product colour | White |
| Buffer size | 12 KB |
| Autocutter durability | 2.2 million cuts |
| Products per pallet | 128 pc(s) |
| Cutter | Yes |
| Print head life | 200.000.000 Impulse |
| Quantity per pack | 1 pc(s) |
| Master (outer) case width | 400 mm |
| Master (outer) case length | 490 mm |
| Master (outer) case height | 255 mm |
| Country of origin | China |
| Products per pallet (UK) | 192 pc(s) |
| Products per master (outer) case | 4 pc(s) |
| Lifetime | 20000000 lines |
| Font styles | ANK |
| Harmonized System (HS) code | 84433210 |
| Features | |
| Mean cycles between failures (MCBF) | 70000000 |
| Character sets | ANK |
| Built-in sensors details | Paper End Sensor, Papier-Sensor |
| Mean time between failures (MTBF) | 360000 h |
| Product colour | White |
| Autocutter durability | 2.2 million cuts |
| Sound pressure level (printing) | 55 dB |
| Compatible memory cards | MicroSD (TransFlash) |
| Card reader integrated | Yes |
| Cutter | Yes |
| Print head life | 200 km |
| Country of origin | China |
| Wall mountable | Yes |
| Mounting position | Horizontal/Vertical |
| Half-cutter | Yes |
| Tablet charge & sync | No |
| Design | |
| Product colour | White |
| Memory | |
| Buffer size | 12 KB |
| Compatible memory cards | MicroSD (TransFlash) |
| Card reader integrated | Yes |
| Endurance | |
| Mean time between failures (MTBF) | 360000 h |
| Power | |
| Power source type | AC |
| Power plug type | Type C |
| Operational conditions | |
| Storage temperature (T-T) | -20 - 60 °C |
| Storage relative humidity (H-H) | 10 - 90% |
| Operating temperature (T-T) | 5 - 45 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Weight & dimensions | |
| Width | 127 mm |
| Depth | 127 mm |
| Height | 127 mm |
| Package width | 195 mm |
| Package depth | 235 mm |
| Package height | 230 mm |
| Package weight | 2.37 kg |
| Weight | 1.3 kg |
| Packaging data | |
| Package width | 195 mm |
| Package depth | 235 mm |
| Package height | 230 mm |
| Package weight | 2.37 kg |
| Cables included | AC |
| Quantity per pack | 1 pc(s) |
| Packaging content | |
| Cables included | AC |
| Quantity per pack | 1 pc(s) |
| Logistics data | |
| Products per pallet | 128 pc(s) |
| Master (outer) case width | 400 mm |
| Master (outer) case length | 490 mm |
| Master (outer) case height | 255 mm |
| Products per pallet (UK) | 192 pc(s) |
| Products per master (outer) case | 4 pc(s) |
| Harmonized System (HS) code | 84433210 |
| Other features | |
| Mean cycles between failures (MCBF) | 70000000 |
| Buffer size | 12 KB |
| Print head life | 200.000.000 Impulse |
| Print head life | 200 km |
