12 SIP Lines, 2 LCDs (Main + DSS), 2.8" + 2.4", 10/100/1000 Mbps, 214 x 188.6 x 181.1 mm
Key Features
- 2.8-inch main color screen and 2.4-inch extended screen for DSS keys
- HD audio on speakerphone and handset
- Support 6-way audio conference
- 3 Line keys on the main display
- 6 DSS keys on the extended screen, up to 30 DSS keys via 5 pages
- Support EHS wireless headset, Wi-Fi dongle or BT dongle □√ Dual Gigabit ports, integrated PoE
- Stand with 2 adjustable angles of 45 and 50 degrees
Description
X4U is an enterprise IP Phone featuring 2.8-inch main color screen and 2.4-inch extended screen, HD voice, gigabit Ethernet, 12 SIP lines, PoE, 6-way audio conference and other extended features like EHS headset, BT dongle and Wi-Fi dongle. It provides the high-quality and convenient experience for users
Specifications
| Features |
|---|
| Handset type |
Wired handset |
| Keypad number of keys |
41 |
| Handset |
Yes |
| Ethernet cable |
Yes |
| Product colour |
Black |
| Backlight keypad |
Yes |
| Technical details |
|---|
| Handset type |
Wired handset |
| Speakerphone |
Yes |
| Keypad number of keys |
41 |
| Handset |
Yes |
| Ethernet cable |
Yes |
| Backlight keypad |
Yes |
| Design |
|---|
| Product type |
IP Phone |
| Handset type |
Wired handset |
| Product colour |
Black |
| Backlight keypad |
Yes |
| Phone features |
|---|
| Lines quantity |
12 lines |
| Caller ID |
Yes |
| Management features |
|---|
| Keypad number of keys |
41 |
| Display |
|---|
| Touchscreen |
No |
| Display resolution |
320 x 240 pixels |
| Display diagonal |
7.11 cm (2.8") |
| Display |
LCD |
| Audio |
|---|
| Speakerphone |
Yes |
| Network |
|---|
| Ethernet LAN interface type |
Gigabit Ethernet |
| Wi-Fi |
Yes |
| Supported network protocols |
IPv4, IPv6 |
| Ethernet LAN |
Yes |
| Bluetooth |
Yes |
| Colour |
|---|
| Product colour |
Black |
| Ports & interfaces |
|---|
| Ethernet LAN (RJ-45) ports |
2 |
| Power |
|---|
| AC adapter output current |
2 A |
| Power over Ethernet (PoE) |
Yes |
| AC adapter output voltage |
5 V |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 45 °C |
| Operating relative humidity (H-H) |
10 - 95% |
| Weight & dimensions |
|---|
| Width |
214 mm |
| Depth |
188.6 mm |
| Height |
181.1 mm |
| Package width |
315 mm |
| Package depth |
228 mm |
| Package height |
84 mm |
| Packaging content |
|---|
| Handset |
Yes |
| Ethernet cable |
Yes |
