1000 VA, 600 W, 110 - 240 V, 3:1, 130 x 320 x 182 mm, 8.2 kg
Key Features
- LCD touch screen
- USB communication port
- RJ45 surge protection
- Compact size
- Excellent microprocessor control for high reliability
- Boost and buck AVR for voltage stabilization
- Auto restart while AC is recovering
- Simulated sine wave
- Off-mode charging
- Cold start function
Description
The iFP series is equipped with automatic voltage regulation to reduce the impact of unstable voltage on equipment. The intelligent UPS’ functions can also provide power during outages, and the battery automatically charges when power is restored. FSP’s intelligent UPS can provide equipment with an uninterrupted supply of power at any time.
Specifications
| Power |
|---|
| Output voltage regulation |
10% |
| Output power |
600 W |
| Input operation voltage (min) |
140 V |
| Input operation voltage (max) |
290 V |
| Output operation voltage (min) |
110 V |
| Output operation voltage (max) |
240 V |
| Output power capacity |
1 kVA |
| Performance |
|---|
| Audible alarm modes |
Alarm when on battery, Fault, Low battery alarm, Overload alarm |
| UPS topology |
Line-Interactive |
| Waveform |
Sine |
| Auto-restart |
Yes |
| Automatic Voltage Regulation (AVR) |
Yes |
| Response time |
6 ms |
| Power protection features |
Battery discharge, Overcharge, Overload |
| Noise level |
40 dB |
| Audible alarm(s) |
Yes |
| Features |
|---|
| Output frequency |
50/60 Hz |
| Audible alarm modes |
Alarm when on battery, Fault, Low battery alarm, Overload alarm |
| UPS topology |
Line-Interactive |
| Waveform |
Sine |
| Output voltage regulation |
10% |
| Auto-restart |
Yes |
| Automatic Voltage Regulation (AVR) |
Yes |
| Response time |
6 ms |
| Output power |
600 W |
| Input operation voltage (min) |
140 V |
| Input operation voltage (max) |
290 V |
| Output operation voltage (min) |
110 V |
| Output operation voltage (max) |
240 V |
| Power protection features |
Battery discharge, Overcharge, Overload |
| Noise level |
40 dB |
| Audible alarm(s) |
Yes |
| Output power capacity |
1 kVA |
| Input frequency |
50/60 Hz |
| Ports & interfaces |
|---|
| USB port |
Yes |
| AC outlets quantity |
2 AC outlet(s) |
| AC outlet types |
Type F |
| USB 2.0 ports quantity |
1 |
| Number of output IEC jumpers |
2 |
| Ethernet LAN (RJ-45) ports |
2 |
| USB port type |
USB Type-B |
| Battery |
|---|
| Number of batteries supported |
2 |
| Battery voltage |
12 V |
| Battery capacity |
7 Ah |
| Cold start |
Yes |
| Design |
|---|
| Form factor |
Mini Tower |
| Product colour |
Black |
| Control type |
Buttons |
| Display type |
LCD |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 40 °C |
| Operating relative humidity (H-H) |
0 - 90% |
| Technical details |
|---|
| Output frequency |
50/60 Hz |
| Sustainability compliance |
Yes |
| Harmonized System (HS) code |
85078000 |
| Compliance certificates |
CE, cTUVus |
| Packaging data |
|---|
| Packaging content |
UPS & user manual |
| Manual |
Yes |
| Certificates |
|---|
| Compliance certificates |
CE, cTUVus |
| Packaging content |
|---|
| Manual |
Yes |
| Batteries included |
Yes |
| Packaging content |
UPS & user manual |
| Sustainability |
|---|
| Sustainability compliance |
Yes |
| Weight & dimensions |
|---|
| Weight |
8.2 kg |
| Width |
130 mm |
| Height |
182 mm |
| Depth |
320 mm |
| Logistics data |
|---|
| Harmonized System (HS) code |
85078000 |
| Other features |
|---|
| Packaging content |
UPS & user manual |
