Description
21.5", 1920x1080, ELED, 14 ms, TF, USB, LAN, WLAN, 8 GB, Android 6.0.1, 516.75x320.03x46.55 mm
Key Features
- Plastic shell appearance, slim frame, and all-in-one design
- Exquisite image, industrial A+ panel, auto-coloring and image-enhancing engine
- Variable materials, static and dynamic materials, including the pictures, audio, video, scrolling subtitle, PDF, webpages, live video, number calling, pop-up pictures, etc
- Flexible program schedule, free schedules and district play of multiple materials and variable play modes: play by day, play by week, play by loop, custom play, etc
- Centralized management, remotely control and manage one screen or more screens, such as timed startup/shutdown, quick startup/shutdown, brightness/volume timed adjustment, and screenshot preview, remotely release programs and updates local (USB) programs
- Organization permission, 5-level organization is available for managing materials, programs, terminals, and users, and support creating custom users, allocating permission for users according to user level, and permission templates
- Multiple security safeguards, 3-level check of materials, programs and schedules to prevent mistake release, encryption of data in storage and transmission to prevent data tampering, and with no default password, users can activate and set initial password to guarantee the password safety
Description
Specifications
| Display | |
|---|---|
| Display number of colours | 16.78 million colours |
| LED backlighting type | Edge-LED |
| Touchscreen | No |
| Active display area (W x H) | 476.64 x 268.11 mm |
| Display technology | LED |
| Display diagonal | 54.6 cm (21.5") |
| Display resolution | 1920 x 1080 pixels |
| Display brightness | 250 cd/m² |
| HD type | Full HD |
| Response time | 6.5 ms |
| Contrast ratio (typical) | 1000:1 |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Pixel pitch | 0.24795 x 0.24795 mm |
| Ports & interfaces | |
| USB port | Yes |
| Wi-Fi | Yes |
| PC Audio in | Yes |
| DisplayPorts quantity | 0 |
| Card reader integrated | Yes |
| Ethernet LAN | Yes |
| HDMI ports quantity | 0 |
| DVI port | No |
| VGA (D-Sub) input ports | 0 |
| Ethernet LAN (RJ-45) ports | 1 |
| USB version | 2.0 |
| USB ports quantity | 2 |
| Audio | |
| Built-in speaker(s) | No |
| Design | |
| Product design | Digital signage flat panel |
| Placement supported | Indoor |
| Product colour | Black |
| Performance | |
| Purpose | Universal |
| Wi-Fi | Yes |
| Power | |
| Power consumption (typical) | 40 W |
| Power consumption (standby) | 10 W |
| AC input voltage | 100-240 V |
| AC input frequency | 50 - 60 Hz |
| Energy efficiency scale | A to G |
| Energy efficiency class (SDR) | G |
| Energy consumption (SDR) per 1000 hours | 18 kWh |
| Computer system | |
| Computer system | Yes |
| Processor cores | 4 |
| Processor family | ARM Cortex |
| Processor model | A17 |
| Processor frequency | 1.8 GHz |
| Operating system installed | Android 8.1 |
| Internal memory | 2 GB |
| Internal storage capacity | 8 GB |
| Built-in processor | Yes |
| Weight & dimensions | |
| Width | 516.8 mm |
| Depth | 46.5 mm |
| Height | 320 mm |
| Weight | 3.03 kg |
| Packaging data | |
| Package width | 593 mm |
| Package depth | 53.5 mm |
| Package height | 320 mm |
| Package weight | 4.63 kg |
| Batteries included | Yes |
| Remote control included | Yes |
| Mounting kit | Yes |
| Cables included | AC |
| Packaging content | |
| Batteries included | Yes |
| Remote control included | Yes |
| Mounting kit | Yes |
| Cables included | AC |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 20 - 90% |
| Storage temperature (T-T) | -20 - 60 °C |
| Storage relative humidity (H-H) | 5 - 90% |
| Network | |
| Wi-Fi | Yes |
| Ethernet LAN | Yes |
| Thin Client | |
| Processor family | ARM Cortex |
| Processor model | A17 |
| Processor frequency | 1.8 GHz |
| Operating system installed | Android 8.1 |
| Internal memory | 2 GB |
| Internal storage capacity | 8 GB |
| Logistics data | |
| Harmonized System (HS) code | 85285210 |
| Features | |
| Harmonized System (HS) code | 85285210 |
| Technical details | |
| LED backlighting type | Edge-LED |
| Other features | |
| Wi-Fi | Yes |
| Display technology | LED |
| Card reader integrated | Yes |
| Energy efficiency scale | A to G |
