USB-C Travel Hub Gen2
Key Features
- UHD external display (4k@30Hz) via HDMI port or FHD display (1080p) via VGA port
- Plug and play
- Support PXE boot & MAC address pass through on selected systems that have enabled these two features
- Require a full functional USB-C port with 5V/3A from PC to work
Description
Lenovo USB-C Travel Hub Gen2 is an essential extension adapter that enables you to easily connect to an external monitor, wired network, and USB device via single robust USB Type-CTM port. Portable design of Lenovo hub is great for traveler. Fewer transition cables and more space in your bag.
Specifications
| Ports & interfaces |
|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
1 |
| Host interface |
USB 2.0 Type-C |
| Ethernet LAN (RJ-45) ports |
1 |
| HDMI ports quantity |
1 |
| VGA (D-Sub) ports quantity |
1 |
| Microphone in |
No |
| DC-in jack |
No |
| Connectivity technology |
Wired |
| Network |
|---|
| Ethernet LAN |
Yes |
| Ethernet LAN (RJ-45) ports |
1 |
| Performance |
|---|
| Product colour |
Grey |
| Card reader integrated |
No |
| Certification |
CE, CB,FCC, EAC, VCCI, KCC, RCM, BSMI |
| HD type |
4K Ultra HD |
| Maximum refresh rate |
60 Hz |
| Hub interfaces |
HDMI, RJ-45, USB Type-C, VGA |
| Technical details |
|---|
| Product colour |
Grey |
| Maximum operating temperature |
60 °C |
| Harmonized System (HS) code |
84719000 |
| Storage |
|---|
| Card reader integrated |
No |
| Power |
|---|
| Input current |
3 A |
| Wireless charging |
No |
| Operational conditions |
|---|
| Operating relative humidity (H-H) |
20 - 95% |
| Weight & dimensions |
|---|
| Weight |
170 g |
| Width |
174 mm |
| Depth |
91 mm |
| Height |
25 mm |
| Package width |
73 mm |
| Package depth |
58 mm |
| Package height |
16.5 mm |
| Design |
|---|
| Product colour |
Grey |
| Certification |
CE, CB,FCC, EAC, VCCI, KCC, RCM, BSMI |
| Packaging data |
|---|
| Quantity per pack |
1 pc(s) |
| Package width |
73 mm |
| Package depth |
58 mm |
| Package height |
16.5 mm |
| Certificates |
|---|
| Certification |
CE, CB,FCC, EAC, VCCI, KCC, RCM, BSMI |
| Packaging content |
|---|
| Quantity per pack |
1 pc(s) |
| Logistics data |
|---|
| Harmonized System (HS) code |
84719000 |
| Other features |
|---|
| Maximum operating temperature |
60 °C |
