Lenovo 4XC1M72800 network card Internal WWAN

ThinkPad Fibocom FM350-GL 5G Sub-6 GHz M.2 WWAN Module for X1 Carbon Gen 11

Key Features

• Fibocom FM350-GL
• Embedded eSIM
• 5G Sub-6 GHz WWAN module
• Dimension: 30 x 52 x 2.3 mm / 1.18 x 2.04 x 0.09 inches
• Interface: M.2 Key-B

Description

ThinkPad Fibocom FM350-GL 5G Sub-6 GHz M.2 WWAN Module for X1 Carbon Gen 11 is a wireless communication module with receive diversity. It helps provide data connectivity and network with PCIe Gen2 M.2 interface. The 5G Sub-6 GHz WWAN module enhances the network reliability and availability of your ThinkPad, and provides a great cellular solution for travelers to sustain mobility while using PC devices.

Specifications

Ports & interfaces
Internal	Yes
Interface	WWAN
Host interface	M.2
Connectivity technology	Wireless
Wireless LAN features
3G standards	HSPA+, UMTS
4G standard	LTE-TDD & LTE-FDD
Technical details
Compatible products	X1 Carbon Gen 11
Product colour	Green
Network
3G standards	HSPA+, UMTS
4G standard	LTE-TDD & LTE-FDD
MU-MIMO	Yes
Mobile network generation	5G
Design
Compatible products	X1 Carbon Gen 11
Product colour	Green
Certification	CE,UKCA,FCC,KC,NCC,C-TICK,MIC
Internal	Yes
Component for	Laptop
Antenna design	Internal
Software
Windows operating systems supported	Windows 11
System requirements
Windows operating systems supported	Windows 11
Operational conditions
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	5 - 95%
Weight & dimensions
Width	30 mm
Depth	52 mm
Height	2.3 mm
Weight	8 g
Package width	53 mm
Package depth	144 mm
Package height	177 mm
Package weight	30 g
Packaging data
Package width	53 mm
Package depth	144 mm
Package height	177 mm
Package weight	30 g
Performance
Compatible products	X1 Carbon Gen 11
Windows operating systems supported	Windows 11
Certificates
Certification	CE,UKCA,FCC,KC,NCC,C-TICK,MIC
