Description
UK Plug, USB C, 20W, GaN, 100-240VAC, 50/60Hz 0.5A, PD 3.0, 40 g
Featuring a single Type C female USB port this charger is ideal for use with most popular smartphones and iOS devices. Supporting power delivery of 20W, connected devices can be provided with faster charging than what is possible from a standard Type C charger supplied with many devices.
For safe charging the device includes overcharge, overcurrent, overtemperature and short circuit protection.
Key Features
- Charges and powers a device via one USB Type C port
- 20W GaN technology provides fast charging for smartphones, tablets, laptops and other mobile devices
- Compact design and lightweight for maximum mobility
- Built-in safety features as overvoltage and overcurrent protection
Description
The Lindy 20W USB Type C PD Charger is a compact, efficient solution for charging many devices. It provides fast charging for USB Type C PD and PPS-enabled devices. Thanks to the small design the charger can easily be carried and is always available when power is needed.Featuring a single Type C female USB port this charger is ideal for use with most popular smartphones and iOS devices. Supporting power delivery of 20W, connected devices can be provided with faster charging than what is possible from a standard Type C charger supplied with many devices.
For safe charging the device includes overcharge, overcurrent, overtemperature and short circuit protection.
Specifications
| Performance | |
|---|---|
| Charger type | Indoor |
| Charger compatibility | Universal |
| Power source type | AC |
| Power protection features | Over current, Over voltage, Overheating, Short circuit |
| Fast charging | Yes |
| Fast charging technology | GaN, Power Delivery 3.0 |
| USB Type-C ports quantity | 1 |
| USB Power Delivery | Yes |
| USB Power Delivery revision | 3.0 |
| Number of simultaneously connected devices (max) | 1 |
| Design | |
| Product colour | White |
| Gallium nitride (GaN) transistors | Yes |
| Housing material | Polyvinyl chloride (PVC) |
| Connector material | Copper |
| Power | |
| Input current | 0.5 A |
| Maximum power | 20 W |
| Input voltage | 100 - 240 V |
| Input frequency | 50 - 60 Hz |
| Maximum output voltage | 12 V |
| Minimum output voltage | 5 V |
| Output current (5V) | 3 A |
| Output current (9V) | 2.22 A |
| Output current (12V) | 1.67 A |
| Output voltage accuracy (±) | 5% |
| Power consumption (no load) | 0.075 W |
| Efficiency at low load (10%) | Yes |
| Average active efficiency | 5V 83.37%, 9V 87.32%,12V 86.40% |
| Compatible power plug types | UK |
| Technical details | |
| Package type | Box |
| Charger type | Indoor |
| Charger compatibility | Universal |
| Power source type | AC |
| Power protection features | Over current, Over voltage, Overheating, Short circuit |
| Manual | Yes |
| Sustainability compliance | Yes |
| Sustainability certificates | ErP |
| Compliance certificates | CE, REACH, RoHS, UKCA |
| Weight & dimensions | |
| Width | 28 mm |
| Depth | 31 mm |
| Height | 29.6 mm |
| Weight | 40 g |
| Package width | 80 mm |
| Package depth | 100 mm |
| Package height | 45 mm |
| Package weight | 60 g |
| Packaging data | |
| Package type | Box |
| Package width | 80 mm |
| Package depth | 100 mm |
| Package height | 45 mm |
| Package weight | 60 g |
| Quantity per pack | 1 pc(s) |
| Operational conditions | |
| Storage temperature (T-T) | -20 - 80 °C |
| Operating temperature (T-T) | 0 - 25 °C |
| Operating relative humidity (H-H) | 0 - 90% |
| Packaging content | |
| Manual | Yes |
| Package type | Box |
| Features | |
| Compatible power plug types | UK |
| Colour | |
| Product colour | White |
| Other features | |
| Manual | Yes |
| Package type | Box |
