Description
4 Port HDMI 8K60 Splitter with Audio
With support for resolutions up to 8K 60Hz 4:4:4 8bit, this splitter is great for creating eye-catching dual display digital signage in retail scenarios, displaying live video across two screens at event venues or distributing engaging multiscreen educational presentations at tradeshows.
The splitter also has separate optical and 3.5mm audio ports to easily extract audio from HDMI® to connect non-HDMI® amplifiers or soundbars, ideal for supporting video with immersive multichannel audio.
The splitters also features an integrated switch to downscale the input signal to 4K or Full HD, making installations with older displays hassle free while always ensuring the viewer receives the optimum picture from their display.
The terms HDMI, HDMI High-Definition Multimedia Interface, HDMI Trade dress and the HDMI Logos are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.
Description
The Lindy 4 Port HDMI® 8K60 Splitter with Audio is a multi-function solution for distributing high quality HDMI® signals across 2 displays simultaneously from one source device, while extracting digital or analogue audio separately.With support for resolutions up to 8K 60Hz 4:4:4 8bit, this splitter is great for creating eye-catching dual display digital signage in retail scenarios, displaying live video across two screens at event venues or distributing engaging multiscreen educational presentations at tradeshows.
The splitter also has separate optical and 3.5mm audio ports to easily extract audio from HDMI® to connect non-HDMI® amplifiers or soundbars, ideal for supporting video with immersive multichannel audio.
The splitters also features an integrated switch to downscale the input signal to 4K or Full HD, making installations with older displays hassle free while always ensuring the viewer receives the optimum picture from their display.
The terms HDMI, HDMI High-Definition Multimedia Interface, HDMI Trade dress and the HDMI Logos are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.
Specifications
| Ports & interfaces | |
|---|---|
| Video ports quantity | 4 |
| Video port type | HDMI |
| Video out | 4x HDMI |
| HDMI version | 2.1 |
| DC-in jack | Yes |
| Headphone out | Yes |
| Headphone connectivity | 3.5 mm |
| Digital audio optical out | 1 |
| Features | |
| LED indicators | Yes |
| Housing material | Metal |
| Maximum refresh rate | 60 Hz |
| Colour depth | 8 bit |
| Maximum resolution | 7680 x 4320 pixels |
| HDCP | Yes |
| Easy to install | Yes |
| Product colour | Black |
| Certification | CE, FCC, RoHS, REACH & California Proposition 65 |
| HD type | 8K Ultra HD |
| HDCP version | 2.3 |
| Data transfer rate | 48 Gbit/s |
| Power | |
| Input current | 2 A |
| AC input voltage | 5 V |
| Weight & dimensions | |
| Weight | 375 g |
| Width | 176 mm |
| Depth | 17 mm |
| Height | 68 mm |
| Package weight | 510 g |
| Package type | Box |
| Package depth | 70 mm |
| Package width | 240 mm |
| Package height | 130 mm |
| Packaging data | |
| Package weight | 510 g |
| Package type | Box |
| Package depth | 70 mm |
| Package width | 240 mm |
| Package height | 130 mm |
| Quantity per pack | 1 pc(s) |
| Packaging content | |
| AC adapter included | Yes |
| Included power plug types | AU, EU, UK |
| Manual | Yes |
| Cables included | Power |
| Package type | Box |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Storage relative humidity (H-H) | 20 - 90% |
| Video | |
| Maximum refresh rate | 60 Hz |
| Colour depth | 8 bit |
| Maximum resolution | 7680 x 4320 pixels |
| HDCP | Yes |
| Colour | |
| Product colour | Black |
| Certificates | |
| Certification | CE, FCC, RoHS, REACH & California Proposition 65 |
| Indication | |
| LED indicators | Yes |
| Technical details | |
| Housing material | Metal |
| Connector 2 | HDMI Type A |
| Connector 1 | 4 x HDMI Type A |
| Package width | 240 mm |
| Package height | 130 mm |
| Video out | 4x HDMI |
| HDMI version | 2.1 |
| Easy to install | Yes |
| Warranty period | 2 year(s) |
| Compliance certificates | CE, Federal Communications Commission (FCC), REACH, RoHS |
| Logistics data | |
| Quantity per pack | 1 pc(s) |
