Description
hEX S (2025)
With 5× Gigabit Ethernet ports (including PoE-in on port #1 and PoE-out on port #5), plus a 2.5 Gigabit SFP cage, this compact router can adapt to many roles. And unlike most ISP boxes, you can assign any port as WAN, LAN, or bridge — full flexibility right out of the box. That’s just the beginning. RouterOS v7 gives you advanced routing, VLANs, bonding, traffic shaping, and more — so you can build the wired network you’ve always wanted.
Description
Need a wired router that won’t slow you down or drain your budget? The new hEX S is a compact, truly budget-friendly device that does a little bit of everything — and does it fast. Whether you’re building a smart home, running a local lab, or just want a clean, powerful wired setup, this is your new Ethernet essential.With 5× Gigabit Ethernet ports (including PoE-in on port #1 and PoE-out on port #5), plus a 2.5 Gigabit SFP cage, this compact router can adapt to many roles. And unlike most ISP boxes, you can assign any port as WAN, LAN, or bridge — full flexibility right out of the box. That’s just the beginning. RouterOS v7 gives you advanced routing, VLANs, bonding, traffic shaping, and more — so you can build the wired network you’ve always wanted.
Specifications
| Ethernet LAN features | |
|---|---|
| Ethernet LAN data rates | 10,100,1000,2500 Mbit/s |
| Memory | |
| Flash memory | 128 MB |
| Internal memory | 512 MB |
| Performance | |
| Processor cores | 2 |
| Operating system installed | RouterOS |
| Internal memory type | DDR3 |
| Flash memory | 128 MB |
| Internal memory | 512 MB |
| Built-in processor | Yes |
| Processor frequency | 950 MHz |
| WAN connection | |
| SFP WAN | Yes |
| Ethernet WAN | Yes |
| DSL WAN | No |
| SIM card slot | No |
| Network | |
| Networking standards | IEEE 802.3af, IEEE 802.3at |
| Ethernet LAN data rates | 10,100,1000,2500 Mbit/s |
| Ethernet interface type | Gigabit Ethernet |
| Ports & interfaces | |
| USB ports quantity | 1 |
| USB version | 3.2 Gen 1 (3.1 Gen 1) |
| Ethernet LAN (RJ-45) ports | 5 |
| DC-in jack | Yes |
| SFP module slots quantity | 1 |
| Protocols | |
| DHCP client | No |
| Technical details | |
| Built-in processor | Yes |
| Processor frequency | 950 MHz |
| Product colour | Black |
| Compliance certificates | CE, EAC, RoHS |
| Certificates | |
| Compliance certificates | CE, EAC, RoHS |
| Packaging content | |
| AC adapter included | Yes |
| Features | |
| Processor cores | 2 |
| Operating system installed | RouterOS |
| Internal memory type | DDR3 |
| Flash memory | 128 MB |
| Internal memory | 512 MB |
| Built-in processor | Yes |
| Processor frequency | 950 MHz |
| Design | |
| Wall mountable | Yes |
| Product colour | Black |
| Power | |
| Power source type | DC, PoE |
| Output voltage | 24 V |
| Output current | 1.2 A |
| Power over Ethernet (PoE) | Yes |
| Operational conditions | |
| Operating temperature (T-T) | -40 - 70 °C |
| Packaging data | |
| AC adapter included | Yes |
