2000VA / 1800W, Online, 4x C13, USB HID, RS-232, Intelligent Slot, EPO, 4x 12V/9Ah, 17.2 kg
Description
- 2000VA / 1800W Online UPS with Power Factor 0.9
- C14 Input, 4x IEC C13 Outlet
- Batteries included: 4x 12V/9Ah
- Online technology with Power Factor 0.9
- Human Interface Device (USB HID) support
- Wide Input Range 100-300VAC for all environments
- Available with integrated batteries
The PowerWalker VFI 1000-3000 TG and its long-run version VFI 1000-3000 TGS offer a professional solution for home and office environment. UPSs are available with internal batteries or alternatively with stronger charger (6A instead of 1A) for an external battery solution.
VFI TG(S) series are detected as HID Power Device by the internal O/S drivers and can be managed without additional software. It finds its application in all dedicated systems for kiosks, ATMs as well as in high security level systems, where additional software is not allowed (i.e. banking).
Specifications
| Power |
|---|
| Output voltage regulation |
-2 - 2% |
| Output frequency regulation |
-0.05 - 0.05 Hz |
| Output power factor |
0.9 |
| Input power factor |
0.99 |
| Output power |
1800 W |
| Input operation voltage (min) |
80 V |
| Input operation voltage (max) |
300 V |
| Output operation voltage (min) |
220 V |
| Output operation voltage (max) |
240 V |
| Efficiency |
90% |
| Emergency Power Off (EPO) |
Yes |
| Crest factor |
3:1 |
| Output power capacity |
2 kVA |
| Charging current |
1.5 A |
| Performance |
|---|
| UPS topology |
Double-conversion (Online) |
| Response time |
4 ms |
| Noise level |
50 dB |
| Features |
|---|
| UPS topology |
Double-conversion (Online) |
| Output voltage regulation |
-2 - 2% |
| Output frequency regulation |
-0.05 - 0.05 Hz |
| Output power factor |
0.9 |
| Input power factor |
0.99 |
| Response time |
4 ms |
| Output power |
1800 W |
| Input operation voltage (min) |
80 V |
| Input operation voltage (max) |
300 V |
| Output operation voltage (min) |
220 V |
| Output operation voltage (max) |
240 V |
| Efficiency |
90% |
| Emergency Power Off (EPO) |
Yes |
| Noise level |
50 dB |
| Crest factor |
3:1 |
| Output power capacity |
2 kVA |
| Input frequency |
40 - 70 Hz |
| Charging current |
1.5 A |
| Ports & interfaces |
|---|
| Emergency Power Off (EPO) connector |
Yes |
| AC outlets quantity |
4 AC outlet(s) |
| AC outlet types |
C13 coupler |
| Power plug |
C14 coupler |
| USB 2.0 ports quantity |
1 |
| RS-232 ports |
1 |
| Battery |
|---|
| Number of batteries supported |
4 |
| Battery voltage |
12 V |
| Battery capacity |
9 Ah |
| Battery recharge time |
4 h |
| Typical backup time at full load |
4.5 min |
| Charging current |
1.5 A |
| Design |
|---|
| Form factor |
Tower |
| Product colour |
Black |
| Cooling type |
Active |
| Display type |
LCD |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 40 °C |
| Operating relative humidity (H-H) |
0 - 95% |
| Technical details |
|---|
| Harmonized System (HS) code |
85078000 |
| Cooling |
|---|
| Cooling type |
Active |
| Weight & dimensions |
|---|
| Package width |
500 mm |
| Package depth |
464 mm |
| Package height |
324 mm |
| Weight |
17.2 kg |
| Width |
190 mm |
| Package weight |
19.6 kg |
| Height |
328 mm |
| Depth |
399 mm |
| Packaging data |
|---|
| Cables included |
Input power cable, USB cable |
| Resource CD |
Yes |
| Manual |
Yes |
| Package width |
500 mm |
| Package depth |
464 mm |
| Package height |
324 mm |
| Package weight |
19.6 kg |
| Packaging content |
|---|
| Cables included |
Input power cable, USB cable |
| Resource CD |
Yes |
| Manual |
Yes |
