Description
PowerWalker VI 2000 RT LCD - 2000VA/1800W, 0-300VAC, 50/60Hz, 430/250 J, 12V / 7Ah, USB, RS-232+, 9x IEC, RJ11 in/out, 28.06kg
- High Frequency Topology
- Pure Sinewave Output
- Output THDV < 3%
- Selectable Line Sensitive
- Swappable LCD Direction
- Extended Run Time
- Power Management Software
- Multi Communication Ports
- Optional SNMP and Relay Card
- Self-Monitoring and Fault Diagnosis
- Load Segments Control
- EPO Connector
Description
PowerWalker VI 2000 RT LCD is a Line-Interactive UPS with pure sine wave, microprocessor control and designed for fulfilling high quantity power protection demand. This series UPS can be applied to standard 19” rack, and the 2U height design facilities your whole system planning and installation.- High Frequency Topology
- Pure Sinewave Output
- Output THDV < 3%
- Selectable Line Sensitive
- Swappable LCD Direction
- Extended Run Time
- Power Management Software
- Multi Communication Ports
- Optional SNMP and Relay Card
- Self-Monitoring and Fault Diagnosis
- Load Segments Control
- EPO Connector
Specifications
| Power | |
|---|---|
| Output power | 1800 W |
| Input operation voltage (min) | 154 V |
| Input operation voltage (max) | 288 V |
| Output operation voltage (min) | 220 V |
| Output operation voltage (max) | 240 V |
| Surge energy rating | 430 J |
| Emergency Power Off (EPO) | Yes |
| Output power capacity | 2 kVA |
| Battery | |
| Battery type | 12V / 7Ah |
| Number of battery cells | 6 |
| Battery recharge time | 4 h |
| Performance | |
| Power protection features | Over power, Overload, Short circuit |
| Noise level | 45 dB |
| Features | |
| Output power | 1800 W |
| Input operation voltage (min) | 154 V |
| Input operation voltage (max) | 288 V |
| Output operation voltage (min) | 220 V |
| Output operation voltage (max) | 240 V |
| Surge energy rating | 430 J |
| Emergency Power Off (EPO) | Yes |
| Power protection features | Over power, Overload, Short circuit |
| Noise level | 45 dB |
| Output power capacity | 2 kVA |
| Input frequency | 50/60 Hz |
| Ports & interfaces | |
| AC outlets quantity | 9 AC outlet(s) |
| AC outlet types | IEC 309 516C6 |
| USB 2.0 ports quantity | 1 |
| RS-232 ports | 1 |
| Modem (RJ-11) ports | 2 |
| Design | |
| Form factor | Rackmount |
| Product colour | Black |
| Display type | LCD |
| Technical details | |
| Harmonized System (HS) code | 85078000 |
| Packaging data | |
| Package dimensions (WxDxH) | 790 x 590 x 236 mm |
| Package weight | 31.9 kg |
| Weight & dimensions | |
| Weight | 28.1 kg |
| Width | 438 mm |
| Package weight | 31.9 kg |
| Height | 86.5 mm |
| Depth | 608 mm |
| Logistics data | |
| Harmonized System (HS) code | 85078000 |
| Other features | |
| Battery type | 12V / 7Ah |
| Package dimensions (WxDxH) | 790 x 590 x 236 mm |
