Description
H.264, LCPM 2.0, 10/100 RJ-45 LAN, 1080p, Miracast , HDMi, VGA, 3.5 mm, USB
App-less and dongle-less screen mirroring
Screen sharing from any device without the need to download an app or keep dongle nearby. ScreenBeam leads with OS-native Wi-Fi Miracast and AirPlay for familiarity and mitigate user training.
Extended desktop
Windows and macOS users can mirror desktop or extend screen to ensure content privacy.
Touch display support
Windows users can markup content directly on room displays, instantly capturing changes in Microsoft Office 365 applications.
Centralized Management
ScreenBeam CMS included for monitor, manage, and update.
Key Features
- Native wireless screen mirroring means no apps or wires
- Trouble-free presenting from anywhere in the room
- Collaborate wirelessly with interactive touch screen support
- Share any form of content, videos, images, slides
- Get meetings started quickly, switch presenters seamlessly
- Extended screen maintains use of device for other actions
- Take advantage of multiport connectivity and high-quality audio
- Designed for commercial applications and dense wireless environments
- Centralized IT management saves resources and budget
- Minimal training required, simple to use
- Connects to displays, projectors, control systems, and Skype Room systems via HDMI and USB
Description
Designed for the needs of small businesses and start-ups to enable hassle-free wireless presentation and collaboration from Windows, Android and Apple devices.App-less and dongle-less screen mirroring
Screen sharing from any device without the need to download an app or keep dongle nearby. ScreenBeam leads with OS-native Wi-Fi Miracast and AirPlay for familiarity and mitigate user training.
Extended desktop
Windows and macOS users can mirror desktop or extend screen to ensure content privacy.
Touch display support
Windows users can markup content directly on room displays, instantly capturing changes in Microsoft Office 365 applications.
Centralized Management
ScreenBeam CMS included for monitor, manage, and update.
Specifications
| Features | |
|---|---|
| HDCP | Yes |
| Video compression formats | H.264 |
| Security algorithms | EAP-TLS, PEAP, WPA-PSK, WPA-TKIP, WPA2-PSK |
| Audio formats supported | LPCM |
| Type | AV receiver |
| Maximum resolution | 1920 x 1080 pixels |
| Supported video modes | 1080p |
| LED indicators | Yes |
| Product colour | Black |
| Supported network protocols | WPA2-PSK (AES), PEAP-MSCHAP V2, EAP-TLS |
| Windows operating systems supported | Windows 10, Windows 8.1 |
| Mac operating systems supported | Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 10.9 Mavericks, Mac OS X 11.0 Big Sur |
| Technical details | |
| HDCP | Yes |
| Wi-Fi | Yes |
| Video compression formats | H.264 |
| Security algorithms | EAP-TLS, PEAP, WPA-PSK, WPA-TKIP, WPA2-PSK |
| Ethernet LAN | Yes |
| Audio formats supported | LPCM |
| Type | AV receiver |
| Maximum resolution | 1920 x 1080 pixels |
| Supported video modes | 1080p |
| Product colour | Black |
| Connectivity technology | Wired & Wireless |
| Supported network protocols | WPA2-PSK (AES), PEAP-MSCHAP V2, EAP-TLS |
| Sustainability compliance | Yes |
| Sustainability certificates | UL ECOLOGO |
| Compliance certificates | CE, RoHS |
| Ports & interfaces | |
| 3.5 mm (1/8-inch) out | Yes |
| USB ports quantity | 1 |
| Wi-Fi | Yes |
| USB version | 2.0 |
| USB connector type | USB Type-A |
| Ethernet LAN | Yes |
| Bluetooth version | 4.0 |
| Bluetooth | Yes |
| RJ-45 input ports | 1 |
| VGA (D-Sub) input ports | 1 |
| VGA (D-Sub) output ports | 1 |
| Number of HDMI outputs | 1 |
| DC-in jack | Yes |
| Connectivity technology | Wired & Wireless |
| Power | |
| Input current | 2 A |
| Power consumption (typical) | 5 W |
| External power adapter | Yes |
| Operating voltage | 5 V |
| Power source type | DC |
| Indication | |
| LED indicators | Yes |
| Operational conditions | |
| Storage relative humidity (H-H) | 5 - 90% |
| Operating relative humidity (H-H) | 10 - 85% |
| Storage temperature (T-T) | 0 - 70 °C |
| Operating temperature (T-T) | 0 - 40 °C |
| Weight & dimensions | |
| Width | 168 mm |
| Package depth | 228.6 mm |
| Height | 34.5 mm |
| Depth | 168 mm |
| Package width | 203.2 mm |
| Package height | 66 mm |
| Package weight | 635.029 g |
| Packaging data | |
| Package depth | 228.6 mm |
| Package width | 203.2 mm |
| Package height | 66 mm |
| Package weight | 635.029 g |
| Packaging content | |
| Cables included | HDMI |
| Quick start guide | Yes |
| AC adapter included | Yes |
| Logistics data | |
| Master (outer) case width | 426.7 mm |
| Master (outer) case length | 609.6 mm |
| Master (outer) case height | 279.4 mm |
| Master (outer) case gross weight | 13.2 kg |
| Products per master (outer) case | 18 pc(s) |
