2× 10 Mbps /100 Mbps RJ45 PoE, 802.3i/802.3u, 71x26x16 mm
Key Features
- 2×10/100 Mbps ports
- Compliance with 802.3af/at devices
- Supplies up to 20 W, which meets the power consumption requirements of most IP cameras
- Extends a PoE/PoE+ network connection an additional 100 m/250 m (10 Mbps mode) from the PoE power sourcing equipment
- Plug and Play, no configuration required
Description
The Fast Ethernet PoE+ Extender TL-POE10E extends a PoE/PoE+ network connection an additional 100m – 250m (10 Mbps Mode) from the PoE power source equipment. TL-POE10E expands network deployment with 802.3af/at PoE compliant devices, making it ideal for remote cabling requirements in surveillance scenarios. Distance will no longer be a barrier to network deployment.
Specifications
| Performance |
|---|
| Plug and Play |
Yes |
| Ethernet LAN data rates |
10,100 Mbit/s |
| Type |
Network repeater |
| Maximum transfer distance |
250 m |
| Data transfer rate |
100 Mbit/s |
| Cable types supported |
Cat5e |
| Auto-negotiation |
Yes |
| Network |
|---|
| Cabling technology |
10/100Base-T(X) |
| Networking standards |
IEEE 802.3i, IEEE 802.3u |
| Ports & interfaces |
|---|
| Power over Ethernet (PoE) ports quantity |
2 |
| Ethernet LAN (RJ-45) ports |
2 |
| Host interface |
RJ-45 |
| RJ-45 output ports |
1 |
| RJ-45 input ports |
1 |
| Design |
|---|
| Housing material |
Plastic |
| LED indicators |
Power |
| Certification |
FCC, CE, RoHS |
| Product colour |
Black |
| Quantity per pack |
1 pc(s) |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 45 °C |
| Storage temperature (T-T) |
-40 - 70 °C |
| Operating relative humidity (H-H) |
10 - 90% |
| Storage relative humidity (H-H) |
5 - 90% |
| Weight & dimensions |
|---|
| Width |
71 mm |
| Depth |
26 mm |
| Height |
16 mm |
| Packaging content |
|---|
| Quick start guide |
Yes |
| Sustainability |
|---|
| Sustainability compliance |
Yes |
| Technical details |
|---|
| Plug and Play |
Yes |
| Ethernet LAN data rates |
10,100 Mbit/s |
| LED indicators |
Power |
| Type |
Network repeater |
| Maximum transfer distance |
250 m |
| Data transfer rate |
100 Mbit/s |
| Cable types supported |
Cat5e |
| Auto-negotiation |
Yes |
| Sustainability compliance |
Yes |
| Compliance certificates |
Federal Communications Commission (FCC), RoHS |
| Colour |
|---|
| Product colour |
Black |
| Certificates |
|---|
| Certification |
FCC, CE, RoHS |
| Compliance certificates |
Federal Communications Commission (FCC), RoHS |
