Description
Intelligent Solar Power Supply System
Control devices centrally, monitor power statistics, get low-battery alerts, update firmware, and reboot
the system via the mobile app. Enjoy peace of mind, no matter your location.
Intelligent Auxiliary Heating Technology
The built-in smart battery supports intelligent auxiliary heating technology, which allows the battery to operate normally across a wide temperature range.
MPPT Controller Boosts Charging Efficiency
An MPPT (Maximum Power Point Tracking) controller optimizes solar panel power, reduce power losses, and increase charging efficiency by 20% compared to PWM (Pulse Width Modulation) controllers.
Key Features
- 90W Photovoltaic Panel and 31.2Ah/10.8V Lithium Battery
- 3× DC Voltage Output Ports
- Modular Design
- 5°/15°/25°/35°/45°/55° Adjustable Angles
- Intelligent Auxiliary Heating Technology
- Maximum Power Point Tracking (MPPT) Charging Controller
- IP66 Weatherproof
- Remote Management and Simple Installation
Description
Remote ManagementControl devices centrally, monitor power statistics, get low-battery alerts, update firmware, and reboot
the system via the mobile app. Enjoy peace of mind, no matter your location.
Intelligent Auxiliary Heating Technology
The built-in smart battery supports intelligent auxiliary heating technology, which allows the battery to operate normally across a wide temperature range.
MPPT Controller Boosts Charging Efficiency
An MPPT (Maximum Power Point Tracking) controller optimizes solar panel power, reduce power losses, and increase charging efficiency by 20% compared to PWM (Pulse Width Modulation) controllers.
Specifications
| Features | |
|---|---|
| Type | Solar panel |
| Placement supported | Outdoor |
| Product colour | White |
| International Protection (IP) code | IP66 |
| LED indicators | Yes |
| Battery capacity | 31200 mAh |
| Battery technology | Lithium |
| Ports & interfaces | |
| Connectivity technology | Wired |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,100 Mbit/s |
| Power | |
| Rated power | 90 W |
| Battery capacity | 31200 mAh |
| Battery technology | Lithium |
| Technical details | |
| Type | Solar panel |
| Placement supported | Outdoor |
| International Protection (IP) code | IP66 |
| Weight & dimensions | |
| Width | 516 mm |
| Weight | 15 kg |
| Height | 60 mm |
| Depth | 998 mm |
| Package weight | 17.5 kg |
| Colour | |
| Product colour | White |
| Packaging data | |
| Package weight | 17.5 kg |
| Packaging content | |
| Quick installation guide | Yes |
| Operational conditions | |
| Operating relative humidity (H-H) | 10 - 90% |
| Operating temperature (T-T) | -30 - 60 °C |
