Description
GbE RJ-45 PoE++, 16 GB LPDDR5, 128 GB SSD, Arm Cortex-A78AE v8.2, 50–57V, 45W, 1.3" touch, -5 - 40°C, Aluminium alloy, 134.2 x 131.2 x 33.7mm, 635g
AI Key works as an edge appliance by receiving smart detections from paired UniFi cameras. Traditionally, Protect cameras are only able to recognize very basic objects such as people and vehicles. AI Key takes these basic smart detections and runs them through a series of advanced AI models to provide powerful new features. While the models used by AI Key provide many useful new features, they might occasionally return inaccurate results. Over time these models will be optimized to improve their accuracy and add additional features.
Description
AI Key is an advanced edge AI appliance designed to elevate your UniFi Protect security system. It enhances detection capabilities with powerful features like NeXT AI natural language search, AI alerts, speech transcription, image enhancement. Setting up the AI Key is quick and straightforward, allowing you to unlock advanced AI-driven insights that transform how you monitor and secure your environment.AI Key works as an edge appliance by receiving smart detections from paired UniFi cameras. Traditionally, Protect cameras are only able to recognize very basic objects such as people and vehicles. AI Key takes these basic smart detections and runs them through a series of advanced AI models to provide powerful new features. While the models used by AI Key provide many useful new features, they might occasionally return inaccurate results. Over time these models will be optimized to improve their accuracy and add additional features.
Specifications
| Design | |
|---|---|
| Certification | IC |
| Product colour | Steel |
| Enclosure material | Aluminium |
| Features | |
| Interface | Ethernet |
| Built-in processor | Yes |
| Performance | |
| Built-in processor | Yes |
| Internal memory type | LPDDR5 |
| Internal memory | 16000 MB |
| Control display unit | Yes |
| Processor model | Cortex-A78AE |
| Processor manufacturer | ARM |
| Processor family | ARM Cortex |
| SSD capacity | 128 GB |
| Detections per hour | 1000 |
| Certification | IC |
| Product colour | Steel |
| Enclosure material | Aluminium |
| Network | |
| Ethernet LAN data rates | 1000 Mbit/s |
| Ports & interfaces | |
| Interface | Ethernet |
| Ethernet LAN (RJ-45) ports | 1 |
| Management features | |
| Reset button | Yes |
| Power | |
| Power over Ethernet (PoE) | Yes |
| Input voltage | 50-57 V |
| Power consumption (max) | 45 W |
| Power over Ethernet (PoE) type supported | PoE++ (4PPoE) |
| Electrostatic Discharge (ESD) protection | Yes |
| Electrostatic Discharge (ESD) protection (air) | 12 kV |
| Electrostatic Discharge (ESD) protection (contact) | 8 kV |
| Electromagnetic (EMP) protection | Yes |
| Electromagnetic (EMP) protection (air) | 12 kV |
| Electromagnetic (EMP) protection (contact) | 8 kV |
| Weight & dimensions | |
| Weight | 635 g |
| Width | 134.2 mm |
| Height | 33.7 mm |
| Depth | 131.2 mm |
| Operational conditions | |
| Operating temperature (T-T) | -5 - 40 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Technical details | |
| Built-in processor | Yes |
| Interface | Ethernet |
| Compliance certificates | CE, Federal Communications Commission (FCC) |
| Memory | |
| Internal memory type | LPDDR5 |
| Internal memory | 16000 MB |
| Display | |
| Touchscreen | Yes |
| Display diagonal | 3.3 cm (1.3") |
| Control display unit | Yes |
| Certificates | |
| Certification | IC |
| Compliance certificates | CE, Federal Communications Commission (FCC) |
