Description
9x GbE RJ45 ports, 18 Gbps, 26.78 Mpps, AC/DC, internal, 240W, 120W PoE, SGCC steel
Description
A switch with integrated 368Wh Lithium-ion battery, capable of providing uninterruptible power for 8 devices.Specifications
| Management features | |
|---|---|
| Reset button | Yes |
| Power | |
| Power connector | AC-in jack |
| Power consumption (max) | 240 W |
| Power supply included | Yes |
| AC input voltage | 110 - 240 V |
| AC input frequency | 50/60 Hz |
| Number of power supply units | 1 |
| Input current | 4.4 A |
| DC input voltage | 48 V |
| Power source | AC |
| Technical details | |
| Form factor | 1U |
| Housing material | Steel |
| Rack mounting | Yes |
| Sustainability compliance | Yes |
| Compliance certificates | CE, Federal Communications Commission (FCC) |
| Ports & interfaces | |
| Basic switching RJ-45 Ethernet ports quantity | 9 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Power connector | AC-in jack |
| Network | |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Data transmission | |
| Switching capacity | 18 Gbit/s |
| Forwarding rate | 26.78 Mpps |
| Throughput | 9 Gbit/s |
| Design | |
| Reset button | Yes |
| Form factor | 1U |
| LED indicators | Yes |
| Housing material | Steel |
| Rack mounting | Yes |
| Indication | |
| LED indicators | Yes |
| Power over Ethernet (PoE) | |
| Power over Ethernet plus (PoE+) ports quantity | 4 |
| Total Power over Ethernet (PoE) budget | 120 W |
| Power over Ethernet (PoE) ports quantity | 4 |
| Power over Ethernet (PoE) | Yes |
| Power over Ethernet (PoE) voltage | 57 V |
| Power over Ethernet 4PPoE (PoE++) ports quantity | 4 |
| Operational conditions | |
| Operating temperature (T-T) | -5 - 40 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Weight & dimensions | |
| Width | 442 mm |
| Depth | 480 mm |
| Height | 44 mm |
| Weight | 9 kg |
| Sustainability | |
| Sustainability compliance | Yes |
| Other features | |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
