SunMAX SolarPoint, (4) 10/100 RJ-45, Wi-Fi (2.4 GHz), IPx4, PoE 17W, DC 24W, 40W Max
Key Features
- Indoor and Outdoor use
- PV Panel Input 10 – 60V
- 4-port 24V PoE output 10/100 switch
- 24V DC-Out Terminal
- Max output power 40W
- External 24V Battery Charging up to 7Amps (supports SLA, AGL, AGM)
Description
SunMAX™ SolarPoint™ is a remote managed MPPT 24V 7A charge controller with a built-in 4 port 24V PoE 10/100Mbps switch and one DC output delivering up to 40W. It comes with built-in weather prediction service, which together with AI algorithms will provide you with critical information about your solar site's existing and future performance.
Specifications
| Ethernet LAN features |
|---|
| Ethernet WAN |
Yes |
| Ethernet LAN interface type |
Fast Ethernet |
| Ethernet LAN |
Yes |
| Ethernet LAN data rates |
10,100 Mbit/s |
| Cabling technology |
10/100Base-T(X) |
| Performance |
|---|
| Memory card slot(s) |
No |
| WAN connection |
|---|
| Ethernet WAN |
Yes |
| Wireless LAN features |
|---|
| Wi-Fi band |
Single-band (2.4 GHz) |
| Network |
|---|
| Ethernet LAN interface type |
Fast Ethernet |
| Ethernet LAN |
Yes |
| Ethernet LAN data rates |
10,100 Mbit/s |
| Cabling technology |
10/100Base-T(X) |
| Mobile network |
|---|
| 3G |
No |
| 4G |
No |
| Ports & interfaces |
|---|
| USB port |
No |
| Ethernet LAN (RJ-45) ports |
4 |
| Memory card slot(s) |
No |
| Design |
|---|
| Product colour |
White |
| Antenna |
|---|
| Antenna design |
Internal |
| Power |
|---|
| Power source type |
DC |
| Power over Ethernet (PoE) |
Yes |
| Operational conditions |
|---|
| Operating temperature (T-T) |
-20 - 50 °C |
| Weight & dimensions |
|---|
| Width |
202 mm |
| Weight |
650 g |
| Height |
50 mm |
| Depth |
186 mm |
